原産地: | 中国(本土) | 銘柄: | ユニークな | モデル番号: | dj | 原産地: | 河北、 中国( 本土) | ブランド名: | ユニークな | モデル番号: | djシリーズ | アプリケーション: | アルミ溶解 | タイプ: | スターラー | 処理タイプ: | 冶金設備 |
包装
包装: | 木の場合 |
aluminium electromagnetic stirrer
can decrease the melt temperature difference to < 5 centigrade; homogenize the chemical composition; reduce melt cycle time by 10~25 percent, cut down power consumption by 10~25 percent; reduce dross generation by 15~25 percent; allay labor intensity, and increase the furnace lining life. Its easy to install and operate; needs for maintenance is very low; and the average service life is longer than 10 years.
Applying furnace capacitye: 1 ton to 120 ton
Rated power: 48Kw to 300Kw
Rated input frequency: 50/60Hz
Rated output frequency: 0.5 to 3.0Hz
Dimensions of induction stirrer (unit:m)
2.22×1.10×0.68
2.30×1.15×0.72
2.40×1.25×0.73
2.75×1.35×0.73
3.10×1.30×1.75
3.30×1.40×1.88
3.85×1.55×1.89
4.40×1.65×2.00
6.00×2.30×2.00
