• 自動粉体塗装ラインconveyorised-金属被膜機械
    商品番号: 10911147
    仕入れる商品へのお問い合わせについて、
    お電話の場合:スタッフに商品番号をお伝えください。
    商品の詳細

    電圧: 顧客ローカル電圧 原産地: 中国(本土) 銘柄: hlc
    条件: 新しい モデル番号: hlc 重量: 他の
    力(W): 他の タイプ: コーティング製造ライン 保証: 2年
    認証: iso9001 次元(L*W*H): カスタマイズされたサイズ 基質: 鉄鋼
    コーティング: 粉体塗装 提供される売り上げ後のサービス: 利用できるエンジニア機械類を海外に整備するため

    包装

    包装: 梱包必要に応じて

    Powder Coating Process:

    Load-Predegreasing-Degreasing-Water Washing-Chrome Treatment-Water Washing-Water Washing-Water Dropping-Drying Oven-cooling-Powder Coating-Powder Curing-Cooling-Unload



    Dedsign Details:

    1. Coating: powder coating

    2. Max.Article: L7600*W100*H1600,aluminium door

    3. Hanger: twin hanging point; Pitch: 400mm

    4. Conveyor Speed: 1.5m/min; 1-3m/min agjustable

    5. Conveyor: P200 heavy duty overhead conveyor

    6. Conveyor Length: 240mtrs with 1 set of 7.5HP motor

    7. Dehydration Oven: T100m rockwool thermal coat board   100,000Kcal natural gas heating system 1 set

        7.5HP thermal insulation blower 1 set for hot air

    8. Powder Curing Oven: T100m rockwool thermal coat board    200,000Kcal natural gas heating system 1 set

       15HP thermal insulation blower 1 set for hot air

    9. Pretreatment: spray type. Water tank & body: SS

    10. Degreasing/Phosphating: 3KW exhaust blower



    Production:

    Max article: L7600*W100*H1600mm    Weight: 7.6kgs*16=120kgs;

    Article Pitch: 8800mm        Production: 9800kgs
