• ビレット鋳造機-鋳造機械
    商品番号: 10905914
    仕入れる商品へのお問い合わせについて、
    お電話の場合:スタッフに商品番号をお伝えください。
    商品の詳細

    原産地: 中国(本土) 銘柄: bolong 条件: 新しい
    保証: 1年 認証: ce 提供される売り上げ後のサービス: 利用できるエンジニア機械類を海外に整備するため
    マシンモデル: 完全にアーク連続鋳造機 ビレット仕様: 正方形の、 ラウンド、 スラブ 半径範囲: R3m-r13m
    鋼の品質: 一般的な炭素/ベアリング/ステンレス鋼 重量: に応じて鋳造量半径とストランド 色: に応じてお客様の再
    サービスが提供される: デザイン、 製造、 インストール、 試運転

    包装

    包装: パッケージ長いのに適している- 距離海の航海

    1. Brief introduction:

    Wuxi Bolong Machinery Co.,Ltd is an  an integrated professional metallurgy machinery manufacturer, capable of providing Equipment Design, Manufacture, Installation, and Commissioning. Our factory is competent to produce all kinds of continuous casting machine with radius from 3 meters to 13 meters, such as round billet, square billets and slabs.





    2. Basic parameters:





    Machine model

    Fully arc continuous casting machine

    Production ability

    Depending on casting radius

    Casting radius

    R3m-R13m

    Billet specification

    Round, square and rectangular (slab)

    Strand quantity

    Depending on output requirement

    Steel quality

    Common carbon steel; bearing steel; low alloy steel and stainless steel, etc.

    Ladle supporting method

    Ladle turret; ladle moving car; fixed ladle support

    Cooling method

    Fully water cooling

    Billet out method

    Hydraulic billet pusher

    Weight

    Depending on casting radius and strand quantity

    Color

    Depending on customers requirement

    Delivery time

    Around 45 working days (without busy schedule)



    3. Standard supply scope:



    Mechanical part

    1

    Ladle turret/ladle moving car/ladle fixed support (determined by customers)

    2

    Tundish

    3

    Tundish car

    4

    Mould

    5

    Mould vibration device

    6

    Vibration drive device

    7

    Protecting cover for vibration device

    8

    Secondary coolings spraying frame

    9

    Secondary coolings spraying pipe

    10

    Spraying nozzle for secondary cooling water

    11

    Support roller device for secondary and thirdly cooling

    12

    Withdrawal straightening machine

    13

    Transmission device for withdrawal straightening machine

    14

    Universal joint

    15

    Rigid dummy bar

    16

    Dummy bar storage device

    17

    Guide roller for dummy bar storage device

    18

    Billet delivery roller table

    19

    Hydraulic billet pusher

    20

    Platform for billet collection

    21

    Flame cutting machine/hydraulic shear (determined by customers)

    Electrics control system

    22

    Control system for mould vibration

    23

    Control system for withdrawal straightening machine

    24

    Effective control system for dummy bar

    25

    Control system for billet delivery roller table

    26

    Control system for billet out

    27

    Control system for central hydraulic station

    Steel structure

    28

    Main casting platform

    29

    Casting platform

    30

    Platform for dummy bar storage

    Auxiliary system

    31

    Hydraulic system

    32

    Discharging device for secondary coolings steam

    33

    Control system for secondary cooling water

    34

    Suspended operation box for withdrawal straightening part

    35

    Special configuration can be provided in accordance with customers requirements



    4.Flow chart:

    ビレット鋳造機



    5. Contact information





    Company

    Wuxi Bolong Machinery Co.,Ltd

    Address

    North, Hudai Industrial Park, Binhu District, Wuxi City

    Zip

    214161

    Telephone

    86 510 8558 3868

    Fax

    86 510 8558 1938
