| 電圧: | 380分の220/400/420/440 | 原産地: | 中国(本土) | 銘柄: | canmade | 条件: | 新しい | モデル番号: | Xk-450 | 重量: | 11490kg | 力(W): | 55キロワット | タイプ: | 開け練りロール機 | 認証: | :2008 | 次元(L*W*H): | 5035x1885x1795mm | 色: | 青 |
包装
| 包装: | 標準的な輸出パッキング |
1.Tailored structure, easy to operate.
2.There are many speeds and speed ratios avasilable, which can satisfy most customers' formula and processing requirements.
3.frame, frame cap and base, looking very nice, are welded and treated by annealing for stress relieving.
4.Chilled alloy cast iron roll is abrasion resistant with long service life.
5.The speed reducer is the hard-tooth surface gear reducer of class 6 prcision, which has long service life and low noise.
6.Perfect emergency stop device can ensure the safety of personnel and equipment.
7.The seal structure with special design can eliminate the leaking phenomenon of lubricating oil.
8.Stock pan is easy to clean up with dislodging device.
9.Human nature designed operating system reduces labor intensity.
10.Modular structure offers various structures for customers' option.
11.The flexible design system can satisfy customers' special design requirements within the shortest time.
12. A load test running will be made to the assembled equipment in our company to save debugging time for customers.
13.Main Technical Parameters
Model Item | X(S)K-160 | X(S)K-250 | X(S)K-305 | X(S)K-360 | X(S)K-400 |
Roll specification (MM) | Φ 160×320 | Φ 250×620 | Φ 305×760 | Φ 360×900 | Φ4001000 |
Max feeding quantity KG/batch) | 10 | 15 | 20 | 25 | 30 |
Front roll speed (M/MIN) | 10 | 16 | 16.3 | 16.22 | 18.7 |
Speed ratio | 1:1.21 | 1:1.17 | 1:1.15 | 1:1.22 | 1:1.17 |
Bearing | Roller bearing | Roller bearing | Roller bearing | Roller bearing | Roller bearing |
Motor power (KW) | 7.5 | 18.5 | 30 | 37 | 45 |
Overall dimension (MM) | 1104×678×1258 | 1870×1026×1730 | 3901×1350×1680 | 4193×1574×1800 | 4578×1755×1805 |
Total weight (KG) | 965 | 2,556 | 4,340 | 6,892 | 9,188 |
