| 構造: | シングルステージポンプ | 原産地: | 中国(本土) | 適用: | ギア | モデル番号: | LBJ-32 | 理論: | 遠心ポンプ | 標準的なか標準外: | 標準 | 燃料: | 電気 | 圧力: | ミドル | 使用法: | 食品、飲料、水、醸造 | 力: | 電気 |
包装
| 包装: | 白い泡袋、 小さな木製ケース、 耐航性のある木製ケース |
Product Description
Product Name: Single-stage single suction food grade centrifugal pump stainless steel sanitary pump
Standard design:
Sanitary pump consists of the flowing parts; motor, cover, shell, connecting support, pump shell II, spindle, mechanical seal, impeller cover, pump shell I, inlet and outlet unios, and four adjustable stainless steel feet.
Materials:
Liquid passing parts: | AISI304 or AISI316L stainless steel |
Other parts: | AISI304 |
Outer surface: | Blasted |
Inner surface: | polishing 0.4 |
Mechanical seal: | EPDM |
Technical data:
Maximum inlet pressure: | 0.5MPa |
Temp. rang: | from -10°C to + 100°C degree |
Noise level( at 1m): | lower than 85dB |
Flushed Seal:
Water pressure: | Max. 0.1MPa |
Water consumption: | 0.25-0.5L/MIN |
Double Mechanical Seal:
Water pressure: | Max. 0.6MPa |
Water consumption: | 0.25-0.5L/MIN |
Voltage and frequency: | 3 stage, 50HZ, 220V-240V/380V-420V/660V-690V |
Motor size: | ABB Motor, 50HZ: 0.75kw, 1.5kw, 2.2kw, 3kw, 4kw, 5.5kw, 7.5kw, 11kw, 15kw |
Packaging & Shipping
Usually packing: white foam bags, small wooden cases, seaworthy wooden cases. Also could as per customer's requirements.
