Characteristic:

1 Static w/o noise and social effects of pollution.Realize energe saving and environment protection.

2 No need maintenance battery which can be recycled 300-500 times.

3 Easy to manage,alternation automatically instantaneously,no need to watch by man.

4 Stable voltage,working reliably,easy for maintenance.

5 Long lifespan which surpasses for 20 years.

6 Adopt 32 digital DPS processor from TI company.

7 Unique advanced SPWM . Adopt Japnese 5th high-speed intelligent power mold.

8 Possess the protection of overcurrent, overvoltage, overload etc.

9 Inspect every battery that are at work and accurately position disabled battery and give off the warning signal to prolong the lifespan of battery.

10 Single-phase series type;0.5 1 1.5 2 2.5 3 4 5 6 7 8 9 10 KVA
three -phase series type;3.3,7 5.5 7.5 11 15 18.5 22 30 and more

Specifications:

1 Input,220VAC ±15%,single phase with two wires,50HZ ±5%.

2 Output,220VAC ±5%,50HZ ±1%,overload capacity: 120%-work normally,

150%- compulsive protection in 1 second.

3Protection:low-voltage,over-voltage,over-load,phase-shortage,short circuit,over-heat,accumulator over-charge, accumulator over-discharge.

4 Transform time:special occasio≤0.25s,ordinary occasion≤3s

5 Standby time:standard:90minites (standby time is optional according to client’s requirements

6 Display screen:LCD,TFT

7 Working environment:Noisy: ≤55Db.Humidity:0~95%.Temperature:-1°C~40°C.The best working temperature:25°C.Altitude: ≤2500m
