Product Description
0.5-2 inch Hydraulic powered tool for metal hole punching(One body) SYK-15
Punching Range | thickness below 3mm(Φ22-Φ60mm) thickness below 2mm(Φ16-Φ115.5mm) |
Punching Force | 15T |
Stroke | 20mm |
Accessories | Φ63, Φ76, Φ80, Φ89, Φ100, Φ114 mm |
Hydraulic Punch Driver | Punching range | Punching force | Weight | Accessories |
SYK-8A | thickness below 3mm (Φ16.5-Φ60.5mm) thickness below 2mm (Φ16-Φ115.5mm) | 8T | 9.5kg | Φ16, Φ20, Φ26.2, Φ32.5, Φ39, Φ51mm |
SYK-8B | thickness below 3mm (Φ16.5-Φ60.5mm) thickness below 2mm (Φ16-Φ115.5mm) | 8T | 10kg | Φ22, Φ27.5, Φ34, Φ43, Φ49, Φ60mm |
SYK-15 | thickness below 3mm (Φ16.5-Φ60.5mm) thickness below 2mm (Φ16-Φ115.5mm) | 15T | 20kg | Φ63, Φ76, Φ89, Φ101, Φ114mm |
Features:
1 The finished distributor, on-off case and plate can change the specification at any time. It can change the size of the tools simply.
2 We can make the hole punch tools according to customer’s requirement, quick delivery.
3 When order rectangle and square tools, please measure the correct dimension.
