| 原産地: | 中国(本土) | 銘柄: | khj | モデル番号: | Kd801/kd802 | 色: | ダークブラウン | 幅のサイズ: | カスタマイズされた | 標準的な長さ: | 33メートル | 厚さ: | 0.045mm~0.065mm | 最高温度: | 280度 | Modlingのプラスチックタイプ: | 型 |
包装
| 包装: | として注文数量当たりの |
Product Construction:
| KD801 | KD802 |
Backing | Polyimide | Polyimide |
Adhesive | Silicone | Silicone |
Application:
Masking for printed circuit boards during wave soldering or solder dip process.
Features:
Employs a proprietary technology that results in extremely low electrostatic discharge at unwind and removal form SUS. Conventional polyimide tape typically generate over 10,000volts during use which can damage around electronic components . The low static properties of KD801/802 can eliminate circuit board degradation.
Storage Details:
Store under normal conditions of 10° to 30°C and 40 to70% R.H. in their initial packaging. Shelf life is 6 months from the date of manufacture.
Remark: Products can be based on the special needs of a variety of thickness and viscosity, as well as anti-static treatment, die-cutting process. Detailed technical parameters can be obtained from the customer service staff.
