製品情報
条件: 新しい | 原産地: 中国(本土) | 銘柄: ヨントン |
モデル番号: Yt-05 | 彫版の速度: ≤50mm/秒( 3または4文字調整可能) | 適用: 100mm*80mm |
次元: 450mm*330mm*670mm | 重量: 15kg | マーキング深さ: 0.1~1mm |
マーキング範囲: 100mm*80mm | 繰り返し精度: ±0.01mm | 空気圧圧力: 0.2~0.6mpa |
硬度の仕事- ピース: hrc≤60 |
包装
包装: 輸出木製ケースで設定1 |
仕様
マーキング- 針はコンピュータで制御、 上に移動し痕跡などの事前- 編集文字やグラフ
Pneumatic marking machine
Principle:
The marking-needle is controlled by the computer, move on traces as pre-edited characters and graphs, to strike materials at a high frequency under the application of compressed air, finally to form the needed characters and graphs on work-piece.
Main Features:
User can engrave on plate conveniently after installed the fixture, and print on the spare parts of machinery after removed.
Software with strong editing function support Windows operating system, easy to use, capable to mark Chinese and English characters, Arabic numbers and graphs, automatic marking serial numbers, international standard VIN codes and scales.
Applications:
Automobile, motorcycle, electric motor car, power equipment, automatic instrumentation, engine, diesel engine, mechanical, machine tools, hardware products, steel, all kinds metal pipe fitting, oil and boiler pipe fittings, gear, pump body, valve, fasteners, aviation, railway, parts of ship, various hard plastic products, etc.
Main tech-specification(Non-standard products can be customized):
Marking range | 100mm×80mm(on plat or curved surface which radian is less than 3mm) | ||
Marking Speed | ≤50mm/s(3 or 4 characters adjustable) | ||
Marking Depth | 0.1~1mm adjustable | Repeat Precision | ±0.01mm |
Pneumatic pressure | 0.2~0.6Mpa | Weight | 33KG |
Power consumption | 100W(not including air compressor and computer) | Size | 450mm×330mm×670mm |
Hardness of work-piece | HRC≤60 | Voltage | 220V±10% 50HZ |
