製品情報
| 原産地: 中国(本土) | 銘柄: 縁石 | モデル番号: Klf1000-40ka/3 |
| 放電電流: 20ka | imax: 40ka | アップ: ≤2.5kv |
| 応答時間: <は25nsで | moq: 5個 | 外殻の材質: 難燃性材料 |
| 寸法( mm): 94*54*66 | キーワード: サージ保護1000vdc太陽光発電 | 作業環境: 温度- 40°c+80°c; 相対湿度< 95％ |
| インストールする: 35mmインストールガイドレール |
包装
| 包装: 標準的な輸出パッキング空気によって。 特別な要件があれば我々はあなたに合うように調整を行うことができ。 |
仕様
1.dクラス。 2.劣化を示すモジュール。 3.極めて迅速対応させていただきます:< は25nsで4.ce、 tuv5.難燃性材料
Protect Solar system by 1000V DC Photovoltaic Surge Protective
1. about product
Feature:
- 380V surge protector.
- High quality pressure sensitive resistance, stable performance
- Indicate deterioration module : green (normal),red (failure).
- Temperature control breaker, build-in over currents fuse protector.
- Extremely quick respond, large intake capacity.
- Small leakage power, long work life, simple maintenance.
- 35mm guide rail installation, standardized module design.
- power supply surge protector and photovoltaic surge protective device .
- DC power.
- DC300V,DC600V,DC1000V,DC1200V for your application.
Application:
electric box or floor distribution box; Distribution box or the power supply front; residential building units a form of a distribution box; room information systems applicable to Class C power distribution box protection; industrial plant electrical distribution box (cabinet) of power protection
Technical Parameters:
TYPE: | KLF300-40KA/3 | KLF600-40KA/3 | KLF1000-40KA/3 |
Protection Class: | D | D | D |
Operating Voltage (Un): | DC300V | DC600V | DC1000 |
Nominal Discharge Current (8/20μs) (In): | 20KA | 20KA | 20KA |
Max. Discharge Current (8/20μ s) (Imax ): | 40KA | 40KA | 40KA |
Voltage Protection Level( Up): | ≤1.5KV | ≤1.8KV | ≤2.5KV |
Response Time: | <25ns | <25ns | <25ns |
Leakage current(μA): | ≤20µA | ≤20µA | ≤20µA |
Working Environment: | Temperature -40°C +80°C;Relative humidity<95%; | ||
Material of Outer Shell: | Flame retardant materials | ||
Dimension(mm): | 94×54×66 | ||
Weight(kg) : | 0.459 | ||
2.Our advantage (WHY SELECT US)
Certification: CE and TUV report
Basic Information:
Shenzhen KaiLiFeng Industry CO.LTD, established in 2004,is a famous Chinese professional manufacturer engaged in the research, development, product, sale and service of control signal surge protector, power surge protector, lightning rod and so on. We are the gold supplier of alibaba,and have aprroved the thirdparty certification,We are located in Shenzhen city, GuangDong Province with convenient transportation access. All of our products have reached advanced level, which makes KLF a new force in lightning protection industry.
Trade Terms:
1. M.O.Q: 5PCS
2. Production lead time: 3-5 days for sample, 7-10 days for mass order.
3. Shipping Port: Shenzhen, China
4. Shipping way: by sea, by air, by express (DHL/UPS/TNT/FedEx/EMS etc.)
5. Shipping freight will be quoted as per your request.
6. Payment terms: T/T, 30% deposit; L/C; Western unio
Our Promise:
1. Provide solutions and high quality products
2. Streamline the buying and paying processes
3. Deliver the goods to our customers all over the world with speed and precision
Good after sales service: one year replacement, five years warranty.
Quality warranty:
We have our own factory, engineer team and a set of equipment for the product test, Beside,we can control the production(also mean we can control the lead-time)quality of the product very well.
More detailed information for surge protector device, pls do not hesitate to inquiry now!
