| 電圧: | 220ボルト、380ボルト | 原産地: | 中国(本土) | 銘柄: | を駅 | 条件: | 新しい | モデル番号: | DZF-6050 | 重量: | 65キログラム | 力(W): | 1400ワット | タイプ: | 乾燥オーブン | 保証: | 一年 | 認証: | iso | 次元(L*W*H): | 415*370*345 | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため | teperature解像度: | 0.1摂氏 | 温度変動: | 約1摂氏 | vauum度: | 133 pa | 温度範囲: | rt〜200摂氏 | 素材: | ステンレス鋼 | 棚: | 1-2ピース | 表示: | デジタル |
包装
| 包装: | 標準輸出木製ケース |
Vacuum Drying Oven/ Laboratory Vacuum Drying Oven
1. Chamber Structure:
The inner chamber is made of stainless steel mirror finish plate while the outer chamber is made of high-quality steel plate sprayed with plastic. A toughened glass observation window is available.
2. Control Method:
Balance temperature and humidity adjusting method.Temperature and humidity control introduces the same channel coordination control method of P.I.D + S.S.R system.Have the function of automatic calculus, and can revise temperature & humidity chan-ge conditions to realize more accurate and stable temperature & humidity control.
3. Features of vacuum drying oven:
1)Microprocessor controller
2)Dual layer tempered glass door for clear observation
3)Minimum heating time 50% less than traditional vacuum oven
4.Application of vacuum drying oven:
Vacuum drying oven is applicable for the drying, baking and sterilizing of nonvolatile articles conducted by industrial and mining enterprises, schools, medical and scientific research institutions.
5. Technical data:
Model | Working room size(mm) | Temp range | Description |
DZF-6020 | 300×300×275 | 50°C~250°C |
|
DZF-6050 | 415×370×345 | ||
DZF-6090 | 450×450×450 | ||
DZF-6210 | 560×640×600 | ||
DZF-6250 | 700×600×600 | ||
DZF-6021 | 300×300×275 | 50°C~200°C | |
DZF-6051 | 415×370×345 | ||
DZF-6052 | Standard temp | ||
DZF-6030A Specialized for chemical industry | 320×320×300 | 50°C~250°C | |
DZF-6030B Specialized for biological industry | |||
DZF-6050B Specialized for biological industry | 415×370×345 | 50°C~65°C |
