| 電圧: | 380ボルト | 原産地: | 中国(本土) | 銘柄: | sl | 条件: | 新しい | モデル番号: | slシリーズ | タイプ: | 真空の乾燥装置 | 保証: | 1年 | 認証: | ce | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため |
包装
| 包装: | 木製ケース |
contact me please:
jassica
skype:jassicamachine
mobile:0086-15838061675
fax:0086-371-86660713
Product description:
1. Dryer machine, also called pipeline type dryer, adopting twice circulate heating system, is our newly developed advanced drying equipment.
2. Wet materials are input into the hopper. The fuel boiler generates hot air which mixes with wet materials and then is sucked into the pipes by the exhaust blower (fan) quickly. And then hot air is flowing and going though the curving pipes and buffer (drying chamber) of dryer, thus wet materials is finished to dry, and the dried materials are discharged from the outlet with air lock.
3. This dryer machine reduces the moisture the moisture to 8-12%. And then you can continue process the material.
Product specification:
Model No. | SLD-1 | SLD-2 | SLD-3 |
Productivity (Kg/hour) | 250-300kg | 600-800kg | 1000-1400kg |
Motor power | 4kw | 5.5kw | 7.5kw |
Weight | 1200kg | 1600kg | 2100 |
Size of the machine | 10*1.0*2.0m | 15*1.0*2.0m | 21*1.2*2.5m |
product show:
