| 電圧: | 380ボルト/415ボルト/460ボルトなど | 原産地: | 中国(本土) | 銘柄: | cmax | モデル番号: | cmax | 重量: | 10-24tons | 力(W): | 23-47kw | 出口の直径: | 0.13ミリメートル0.2ミリメートル | 保証: | 一年 | 条件: | 新しい | 認証: | ce iso共同 | 次元(L*W*H): | 1970*1200*1200 (mm) (ミリメートル)など | 入口の直径: | 7.0 8.0 9.0ミリメートルなど | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため | マシンタイプ: | ビッグ/ミドル/小さな描画機 | 機器: | 延伸機、annealers、を支払う-オフ機ct | putoutワイヤー: | 0.13ミリメートル、0.2ミリメートルなど | にワイヤー: | 7.0 8.0 9.0 mmetc |
包装
| 包装: | としてクライアントの要求 |
Specifications
Stainless steel Wire drawing Machinery
1.Length of coil nail:25-100mm
2.Diameter of coil nail:1.8-4.5mm
Stainless steel Wire drawing Machinery
Stainless steel Wire drawing Machinery :
Data | Five drums | Four drums | Three drums | Two drums |
Diameter(mm) | 550-600 | 550-600 | 550-600 | 550-600 |
Max inlet diameter(mm) | 6.5 | 6.5 | 6.5 | 6.5 |
Min outlet diameter (mm) | 3.0 | 3.8-4.0 | 4.5 | 4.8 |
Moulds(pcs) | 5 | 4 | 3 | 2 |
Linear velocity(m/min) | 216 | 120-160 | 120-160 | 120-160 |
Motor power(KW) | 60 | 45 | 35 | 27 |
Lubricant type | powder | |||
this Stainless steel Wire drawing Machinery
can draw low, medium and high rate carbon steel wires, stainless steel wires, prestressed wire, alloy steel wires and so on, which are suitable for making cord yarn steel wire, rubber hose steel wire, spring steel wire, temper steel head wire, gas-protection welding wire, and stainless steel wire.
Function:
This Stainless steel Wire drawing Machinery
nis used to draw iron, copper, aluminium wires, mainly for mesh weaving, construction, galvanization, or supply for the wire drawin of water tank.
This Stainless steel Wire drawing Machinery includes 2 drum-uint,3 drum-uint, 4drum-unit, 5drum-unit.wire drawing machines can be ordered according to the need of our customers.
