| 原産地: | 中国(本土) | 銘柄: | AGTPOS | モデル番号: | AGT-960EZ | COLOR: | BLACK,WHITE |
Features
- 1. True flat designing
- 2. Multi-touch with capacitive screen
- 3. Fanless POS will be quite
- 4. Excellent cable management hides cables from view eliminating accidental disconnection for a clean, professional look
- 5. Simple method on hard disk move and fit, convenient maintenance
- 6. Dismountable base make various function, VESA or stand
- 7. IP65 at front panel
Expand peripherals as module integration
Model name | AGT-960ER |
color | Black |
optional | 1*2*3 track card reader |
Customer Display: VFD | |
Second Screen | |
WIFI | |
I-button | |
RFID | |
motherboard |
|
chipset | Intel® NM70 Chipset |
CPU | Intel® 1037U dual core 1.8G |
BIOS | AMI 16MBit SPI BIOS |
Memory | DDRIII 2GB |
HDD | 320G SATAII HDD or 32G SSD |
LAN | RealTek 8111E Gigabit Ethernet |
Audio | RealTek ALC661 HD audio decode |
display |
|
LCD panel Size | 15＂ TFT LCD display |
Pixel pitch | 0.297(H)×0.297(V) mm |
Display area | 304.128(H)×228.096(V) mm |
Contrast Ratio | 700:1 |
View angel | R/L ＋80°~－80° |
U/D ＋70°~－70° | |
brightness | 450cd /㎡ |
Display color | 16.2M |
resolution | XGA 1024×768 @ 60Hz |
Touch screen | G+G multi points capacitive touch |
Touch interface | USB built in |
Operating temperature | 20﹪~80﹪ |
Storage Temperature | 0℃~40℃ |
Operating humidity | 20﹪~80﹪ |
Storage humidity | －20℃~60℃ |
I/O
| VGA 15-pin-D-SUB |
PS/2 KB | |
COM3 W/ DB9 port | |
COM2.4.5 W/RJ45 port | |
USB2.0*4 | |
LAN*1 | |
Headset*1 | |
12V DC out*1 | |
RJ11 for cash drawer*1 | |
12V DC In*1 | |
Power switch *1 | |
Reset switch *1 | |
Size | 465*305*410MM |
N.W | 6.1KG |
G.W | 8KG |
Accessories | 12/5A adaptor，power cable，CD driver， |
Consumption | 40W（MAX） |
