| 原産地: | 中国(本土) | 銘柄: | kvsio | モデル番号: | KVS-9207 | モニター: | 42 " 46 " 55 " led/lcd | タッチスクリーン: | 抵抗 | アプリケーション: | 屋内 |
包装
| 包装: | バブルの泡、 カートン、 木製ケース |
Basic functions:
- Internet/information access
- Account inquiry & transfer
- Retail/ ordering/ payment
- Ticketing/photo/card printing
- Tel / transport card recharging
- Photos, ring tones download
- Product information release
Optional functions:
- Collection pay for utility bills, telephone/ broadband fees
- Foreign currency exchange, bonds and funds business
- Invoices printing, card issuing, multi-media input/output
- Personal authentication, attendance, change
Basic Configurations:
- Powerful Regular PC or Industrial PC
- 32, 42, 46, 55 inch above LED monitor
- 32, 42, 46, 55 inch or above SAW/Infrared/Resistance/Capacity touch screen
- Manual insert or motorized card reader for magnetic/IC cards reading
- Cash acceptor( 20pcs/bundle)
- Cash dispenser( 1, 2, 3, 4 cassette optional)
- Rugged metal PC keyboard or metal Encrypted pin pad/EPP
- Thermal/dot matrix Receipt Printer, 60/80/112mm paper width, with auto cutter
- Multi-media Speakers
- OS Window XP2003( test or licensed version)
- All Steel made Enclosure(stainless steel, aluminum optional)
- Power coating or automobile paint
- LOGO&Color upon request
Optional Configurations:
- Following components can be integrated into Kiosk upon specific application requirement.
- Coin Acceptor
- Coin Hopper
- Check Reader
- Passport Reader
- Fingerprint Reader
- Bar-code Scanner
- Card printer
- Card dispenser
- A4 laser/thermal printer
- Wireless connective (WIFI/GSM/GPRS)
- UPS
- Telephone
- Camera
- Motion Sensor
- Air conditioner
Standard Configurations:
| Components | Model No. | Detailed Discription | |||||
| Computer parts | PC | Motherboard: Intel G41 | |||||
| CPU:E5700 | |||||||
| RAM:2GB; Hard Disk:160G 7200r | |||||||
| 1 RS-232 Ports;2 LTP;4 USB Ports,1 10/100M Net Port | |||||||
| Integrated Net Card, Sound Card, Video card | |||||||
| Computer case and power supply | |||||||
| Monitor | 32"/42"/46"/55"LED | Brightness: 400cd/m2 | |||||
| Contrast: 1600:1 | |||||||
| Response Time:8ms;Dot pitch: 0.297; | |||||||
| Resolution:1920×1080 | |||||||
| Touch Monitor | 32"/42"/46"/55"Infrared Multi-touch | High Transparence, high precision and durability | |||||
| antirust,anti-acid,anti-dust | |||||||
| Max Resolution: 4096×4096 | |||||||
| Force<100G; Response Time:<16ms | |||||||
| Speakers | Left and right bi-channel; amplified output; Multimedia speaker | ||||||
| WiFi | TP-link TL-WN350G | Wireless Standard:IEEE 802.11b,IEEE 802.11g/Transmit Transmitting speed rate:11g:54, 48, 36, 24, 18, 12, 9, 6M(Auto adaptive), 11b:11, 5.5, 2, 1M(Auto adaptive)Mbps/Interface:PCI port,32 digits PCI 2.1, 2.2, 2.3/Covering range: indoor Max. 100M, outdoor Max.300M | |||||
| Enclosure | KVS-9207A | Durable steel frame, powder coated; Slim and smart design; Easy to install and operate; Moistureproof,Antirust,Anti-acid,Anti-dust,Static free, ATM level paint,Color upon request. | |||||
| OS Software | Microsoft Windows 7(trial version), all hard drives are available | ||||||
| Packing | Bubble Foam, Carton, Wooden Case | ||||||
