| 原産地: | 中国(本土) | 銘柄: | 日の出 | モデル番号: | Cd-406 | タイプ: | タイミングベルト | 標準的なか標準外: | 標準 | 材料: | ゴム | 材料: | epdm | パッキング: | polybagおよびカートン | oem: | 1145a019 | 支払: | Tt、 l/c、 ウェスタンユニオン |
包装
| 包装: | polybagおよびカートンメーカー三星ベルトユニークな製品をカスタマイズすることができ |
Unique product manufacturer MITSUBOSHI belt can be customized
Product Description:
1.Using nylon 66 high stretch on tooth surface for protection;
2.Skeleton material is high quality glass fiber cord imported from Japan;
3. With dynamic bend resistance, fatigue performance is good;
4. Anti- aging, heat resistant, oil resistant, wear resistance etc;
5. imported high quality synthetic neoprene as the main raw material.
Specification Availability:
| Type | pb | ht | hs |
| MR | 9.525 | 3.54 | 5.69 |
| MY | 8.00 | 3.06 | 5.21 |
| YU | 8.00 | 3.11 | 5.20 |
| RU | 9.525 | 3.56 | 5.70 |
| ZA | 9.525 | 1.91 | 4.10 |
| ZB | 9.525 | 2.29 | 4.50 |
| ZBS | 9.525 | 2.76 | 5.06 |
| ZAS | 9.525 | 2.32 | 4.5 |
| S8M | 8.00 | 3.05 | 5.30 |
| ZLB | 9.525 | 2.7 | 5.05 |
| RPP | 9.525 | 2.25 | 4.50 |
IUnique product manufacturer MITSUBOSHI belt can be customized
Belt, automotive belt, rubber belt, the industrial belt
Arc tooth synchronous belt(mm)
| Gear Code | Type | Pitch | Tooth Heigh | Belt Thickness |
| HTD | 2M | 2 | 0.75 | 1.36 |
| 3M | 3 | 1.17 | 2.4 | |
| 5M | 5 | 2.06 | 3.8 | |
| 8M | 8 | 3.36 | 6.00 | |
| 14M | 14 | 6.02 | 10.00 | |
| 20M | 20 | 8.4 | 13.20 | |
| STD | S2M | 2 | 0.76 | 1.36 |
| S3M | 3 | 1.14 | 2.20 | |
| S4.5M | 4.5 | 1.71 | 2.81 | |
| S5M | 5 | 1.91 | 3.4 | |
| S8M | 8 | 3.05 | 5.3 | |
| S14M | 14 | 5.3 | 10.2 | |
| RPP/HPPD | RP2M | 2 | 0.76 | 1.36 |
| RP3M | 3 | 1.15 | 1.9 | |
| RP5M | 5 | 1.95 | 3.5 | |
| RP8M | 8 | 3.2 | 5.5 | |
| RP14M | 14 | 6.00 | 10 |
Double Sided Timing Belt(mm)
| Type | W | T |
| D-MXL | 0.508 | 1.53 |
| D-XL | 0.508 | 3.05 |
| D-L | 0.762 | 4.56 |
| D-H | 1.372 | 5.95 |
| D-XH | 2.794 | 15.49 |
| D-XXH | 3.048 | 22.11 |
| D-T2.5 | 0.6 | 2 |
| D-T5 | 1 | 3.4 |
| D-T10 | 2 | 7 |
| D-T20 | 3 | 13 |
| D-AT10 | 2 | 7 |
| HTD.DA-3M | 0.76 | 3.1 |
| HTD.DA-5M | 1.143 | 5.26 |
| HTD.DA-8M | 1.372 | 8.17 |
| HTD.DA-14M | 2.8 | 14.84 |
| HTD.DA-S8M | 1.372 | 7.48 |
FAQ:
We also supplied special size and design automotive timing belt, if required, pls provide us samples or drawing.
NOTE: when make an order or inquiry, any OE number, part number of others are available to check. Engine and Vehicle model will be available to offer the price and belts accordingly.
Welcome inquiry questioning Price
