| 原産地: | 中国(本土) | 銘柄: | okeler | モデル番号: | tha001 | タイプ: | スプリッタスイッチ | hdmiバージョン: | 1.3 | インターフェイスの種類: | で1hdmi、 2hdmi出力 | ビデオ信号入力: | ボルトp-p0.5から1.0。 | 単一リンク範囲: | 1920×12001080p | hdmi解像度: | 480i/576iで/480p/576p/720p/1080i/1080p | 帯域幅: | まで225mhzの |
包装
| 包装: | カラーボックス |
Full HD HDMI Splitter switch 1x4 port out support 1080p, dvd,3D
Description:
1.This 1x2 HDMI splitter distributes the HDMI input into two identical, synchronized outputs.
2. The splitter also has the ability of buffering and amplifying, and can achieve long distance transmission of HDMI signal of up to 15 meters.
3. When two or more splitters are cascaded they can be used to create a larger distribution.
4. This splitter offers an ideal solution for HDTV retail and show site which is suitable for HDTV, STB, DVD and projector, data center control, information distribution, conference room presentation, school and corporate training environment.
Note: We support 3 plug standard,they are EU, Australia, US type. And the standard of them will be send according to your geographic position of your country.
Support:
- Supports HDMI 1.3, 1080p video solution, bandwidth up to 225MHz
- Supports 3D (If your devices support 3D)
- Supports HDCP, 8bit per channel (24bit all channel) deep color
- Supports uncompressed audio such as LPCM, DTS-HD and Dolby True HD
- Cascaded: Large distribution achieved by cascading more HDMI Amplifier Splitter
Specification:
- Product type: 1 in 2 out HDMI Splitter
- HDMI version: 1.3
- Interface type: 1 HDMI in, 2 HDMI out
- Input video signal: 0.5-1.0 volts p-p.
- Input DDC signal: 5 volts p-p (TTL)
- Single link range: 1920 x 1200 1080p
- HDMI resolution: 480i/576i/480p/576p/720p/1080i/1080p
- Bandwidth: Up to 225MHz
- EIDI duration: 4 seconds
- Power supply: DC 5V 1A
- Working distance (Max.): 33 feet (10 m) by 28AWG HDMI cable; 50 feet (15 m) by 26AWG HDMI cable
