| 原産地: | 中国(本土) | 銘柄: | KAGUWI | モデル番号: | KGW-700C | タイプ: | 麻酔の装置及び付属品 |
包装
| 包装: | 合板のケースに詰め |
仕様
Anesthesia Machine ,Portable Anesthesia Machine ,ICU Anesthesia Machine , Anesthesia Machine with Ventilator
- CE marked
- Applicable to pediatric and adult.
- Electronic flowmeter.
- 8.0 inch TFT screen
- Highly integrated absorber to avoid cross-infection.
- Highly integrated absorber, autoclavable in 134°C to avoid cross-infection( optional)
- The standard absorber could be automatically heated, to avoid water condensation.
- AGSS(Anesthesia Gas Scavenging System) is optional
Reliable Quality
- Vaporizer with CE mark, and with automatic compensation for temperature, pressure and flow. Interlock for two positions to ensure anesthetic accuracy.
- World leading brands of flow sensor, differential pressure sensor, pressure regulating valve and proportional valve to ensure accurate ventilation.
- Close-loop (optional) control to offer real-time compensation for fresh gas, absorber compliance and system leakage.
- Patented technology of proportional valve, simultaneous monitoring of inspiration and expiration
- Safe valves for gas supply, driving gas and fresh gas; multiple pressure and volume protection.
- Audio and visual alarms with three levels.
Comprehensive Function
Excellent anesthesia ventilator
- For patients at different ages, pediatric and adult.
- Various ventilation modes: VCV, PCV, SIMV+VCV+PSV , Manual, Standby
Sophisticated monitoring
- Respiratory parameter monitoring
- Resistance(R), Compliance(C), PEEP, I:E
- Waveform: P-T, F-T, V-T,
- Loops(optional) : V-P, F-V, F-P
Specification KGW- 700C | |
Anesthesia ventilator |
|
Ventilation mode | VCV,PCV,SIMV+VCV+PSV, Manual, Standby |
Tidal volume(VT) | 40~1500 mL |
Frequency (f) | 4 ~ 60 bpm |
I:E | 3:1~1:6(Increment0.5) |
Ti | 0.1~10 s(Increment0.1 s) |
Inspiratory pause (Tp) | OFF,5%~50% |
E-PEEP | Integrated electronic PEEP OFF,4~20 cmH2O |
Flow trigger (FTRIG) | 1~15 L/min |
Pressure control | 5~70 cmH2O |
Pressure support Pressure Limit | 5~60 cmH2O PEEP+5~PEEP+70 cmH2O |
Monitoring parameters | C, R, VTE, VTI, MV, MVspn, f, fspn, I:E, Ppeak, Pmean, Pplat, Pmini |
Pneumatically |
|
Gas supply | Pipeline supplyO2, N2O; Yoke: 1x O2 ;1x N2O; |
Pressure gauge | Mechanical |
Flow meter | electronic flow meters for O2, N2O O2 and N2O linkage and N2O cutoff function |
Bellows volume | Adult,0~1500 mL,pediatric(optional),0~300 mL |
APL valve | 2~70 cmH2O |
CO2 Canister Volume By-pass | 1.5 L(1.35 Kg) Automatic; change soda lime during operation. |
bag/vent switch | switch for manual ventilation and mechanical ventilation |
Monitoring |
|
Waveform | P-T, F-T, V-T, |
Loop | V-P, F-V, F-P (optional) |
Alarm setting | VT, MV, f, FiO2, Airway pressure, High continuous airway pressure, Negative pressure, Apnea, O2 supply failure, Mains failure, Battery low capacity, Battery exhausted. |
Alarm mute | < 120s |
Vaporizer | 2 stations |
Physically |
|
Screen | 8.0 inch TFT screen |
Dimension | 1570×850×740 mm3(H×W×D) |
Net weight | 86 Kg(Kg (only framework) |
Power | 100 to 240 VAC,50/60 Hz,10A(Max.) |
Lithium Battery | 120 minutes |
Communication connector | VGA,RS232,RJ45,debugging interface |
