製品情報
| 適用: プラスチック | 材料: アルミニウム | 原産地: 中国(本土) |
| 銘柄: Tamprinter | モデル番号: TGM-200A |
包装
| 包装: plywood case/carton |
仕様
Temperature control:PID control Heating plate:170120mm Max stamping size:150100mm Table area:280380mm
Technical parameter：
Dimensions | W870D670XH1750mm |
Power | Heating power1600W Total power 2.0KW |
Power consumption | ab0ut 0.7KW/h |
Temperature control | PID control |
Stamping method | Pressing |
Heating plate | 170120mm |
Max stamping size | 150100mm |
Table area | 280380mm |
Roll film way | Regular automatic roll film |
Film feeding motor | 6W Electrical motor |
Pressing cylinder | 100DIM80mm |
Air pressure | 0.5～0.7Mpa(5～7bar) |
Max stamping pressure | 6Kg/cm² |
Power supply | 220V/50Hz，2.0KW |
Net weight | ab0ut 180Kg |
Application Scope:
It is applied to local stamping products, such as: product LOGO, trademark, fonts, decorative edge, pattern and so on.
