製品情報
| 原産地: 中国(本土) | 銘柄: エキス | モデル番号: Pu-h500 |
| 材料: ポリウレタン100％ | 標準的な硬さ: 55、 60、 65、 70、 75、 80、 85、 90、 95、 岸 | 標準サイズ: 25*5,30*5,30*8,35*8,35*9,40*7,40*8,50*8,50*9,50*10mm |
| 標準色: 赤、 青、 緑、 白、 黄色、 コーヒーなど | 標準的な長さ: 千ミリメートル、 1200ミリメートル、 3000ミリメートル、 3600ミリメートル、 3660mm、 3700mm | 標準プロファイル: 正方形のエッジストレート、 シングルベベル、 ダブルベベル |
包装
| 包装: カートンで、 プラスチック包装や顧客の要求として |
仕様
1.工場出荷時の価格とパーソナライズサービス2.高強度3.摩耗- 抵抗4.オイル- 抵抗5.良い再- shapening
SHENZE ShengDa Rubber Squeegees for Screen Printing
SHENGDA squeegees has been developed – thanks to the great experience of all Tecno's crew – to satisfy all screen printing industry demands.
The SHENGDA EXTRACT Squeegee– in its Standard,PU-H100, PU-H300, PU-H500, PU-H700 PU-HD1
– guarantees a high resistance to abrasion, solvents and inks. Moreover, our advanced cutting and chamfering techniques along with our skilled operators’ know how ensure uniformity of profiles: high printing precision is assured.
The quality of all our squeegees has been tested directly by screen printers, in different printing field: the excellent feedbacks confirm the already positive results we obtain in chemical lab tests.
DIMENSIONS AND HARDNESS
Our squeegees are available in the following dimensions:
- HARDNESS: from 50 Sh A to 95 Sh A
- LENGTH: 1000mm,1200mm,3000mm,3600mm,3660mm,3700mm,4100mm – we can also cut squeegees following your specific requests
- WIDTH: from 20 mm up to mm 100
- THICKNESS: from mm 4 up to mm 10
- STANDARD SIZE: 25*5,30*5,30*8,35*8,35*9,40*7,40*8,50*8,50*9,50*10mm
- STANDARD COLOR :yellow ,blue,white,red,coffee,green etc ,available for your request
COLOURS AND HARDNESS
We usually produce squeegees in the international standard colours, according to the hardness:
- Red 60 ,65 SH
- Green 70,75 SH
- Blue 80 ,85 SH
We can also produce different profiles, according to your request.
HOW TO CHOOSE A PROFILE
The profile of the Squeegee determines the thickness of the ink deposit laid down: how much ink you need to deposit on the surface you are printing.
SQUARE EDGE P0: the most common squeegees, they are mainly used on cylinder, textile, and manual presses.
ROUND EDGE P5,P6,P7: generally used in the textile industry, when a very heavy ink deposit is required.
BEVELED EDGE (“V”SHAPE) P1,P3: they are typically used for printing rounded surfaces where high definition is required efficient on high-speed automatic machines.
PROFILI P2,P8: more specific applications.RANGE OF PRODUCTS
Along with our standard SHENGDA rubber squeegees, we can supply special products. They are characterized by specific formulations according to the different final applications.PU-H100,PU-H300
Usually used in garment and textile printing. Suitable for manual and automatic printing, resistant to water-based inks and common solvents.
PU-H300,PU-H500
High resistance squeegee, with optimal abrasion and chemical resistance. Perfect for high-speed printing (glass printing, cd printing, credit card printing...)
PU-H500,PU-H700
Specifically conceived for high definition printing with UV and Vinyl inks. Highly recommended for printing on PVC, Polycarbonate, Polyesters, Aluminium.
PU-H300,PU-H500,PU-H700
Realized to reduce dust deposits and optimize printing precision. The Anti-static formulation avoids electrostatic charges, even if the squeegee is used at a fast speed.
PU-HD1
This squeegee has been developed to meet the most demanding customers' needs.
It is highly resistant to abrasion and to the most aggressive inks and solvents. The special formulation reduces the swelling of the squeegee, granting a longer lifetime of the blade.
Especially conceived for high-speed automatic printing, glass printing, cd printing, credit card printing, and all industrial and electronic printing.THE SCREEN PRINTING PROCESS and T-SHIRT PRINTING :
