製品情報
| 原産地: 中国(本土) | 銘柄: ACT | モデル番号: ER14250 |
| 電池のタイプ: LiSOCl2 | わずかな電圧: 3.6V | サイズ: 1/2AA |
| わずかな容量: 1.2Ah | continuous current: 20mA | pulse current: 50mA |
| certification: UL/UN/CE | weight: 9g | temperature: -55°C ~ 85°C |
包装
| 包装: standard package |
ACT ER14250 lithium battery
Specification
1, high power 3.6v lithium battery.
2, 14.5mm(diameter)*25.2mm(height).
3, 1/2AA 3.6V/1.2Ah, 9g weight.
4, work at -55°C-85°C.
5, max continuous current 20mA at 20°C.
.............................................................................................................................................................................
♣ Products Characteristics:
| Model No. | Capacity | Voltage | temperature | Max. continuous current | Max.Dimensions | Weight | height |
| ER14250 | 1.2( Ah ) | 3.6(V) | -55 ~ +85( °C ) | 20(mA) | 14.5( mm ) | 9g | 25.2mm |
Open circuit woltage(At 20 °C): 3.66V
Pulse capability:Typically up to 50mA
Storage(recommended): +30°C (+86 °F)Max
Operating temperature range: -55 °C ~+85 °C
Avai lable terminal suffix: radial tabs,radial pins,axial leads,flying leads
..............................................................................................................................................................................................................................
♣ Certification Show:
.............................................................................................................................................................................................................................
More information: http://act-battery.en.alibaba.com
