製品情報
| 原産地: 中国(本土) | 銘柄: ACT | モデル番号: ER14335 |
| 電池のタイプ: LiSOCl2 | わずかな電圧: 3.6V | サイズ: 2/3AA |
| わずかな容量: 1650mAh | Nominal Capacity: 1650mAh | Nominal Voltage: 3.6v |
| Size: 2/3AA | Type: Energy type | Battery shape: Cylindrical |
包装
| 包装: Packing with industrial/exported cartons. |
仕様
3.6 Volt 2/3 AA 1650 mAh (ER14335) Primary Lithium Battery
1, Professional manufacturers for lithium battery
2, CE/SGS/UL/UN
3.6 Volt 2/3 AA 1650 mAh (ER14335) Primary Lithium Battery Specifications:
- Chemistry: Lithium-thionyl chloride (Li-SOCl2) technology
- Nominal capacity: 1650 mAh
- Open circuit voltage: 3.66V (at +20C +68F)
- Nominal voltage: 3.6V (at 1mA +20C +68F)
- Max. Continuous current: 70 mA Max
- Pulse current: 140 mA
- Brand: Ahead Cell Technology(ACT)
- Storage Temperature: +30C +86 F max (recommended)
- Operating temperature: -55C / +85C
- Diameter(max): 14.5mm (0.55 in)
- Height (max): 33.5mm (1.32 in)
- Typical weight: 12g (0.5oz)
Main applications:
- Backup power for circuit board.
- General purpose; camera/electronic cells
- Medical equipment; military/aerospace
- Telecommunications; water/electricity meter
- LED lighting applications
- Others
Equivalent Batteries
- Tadiran TL-2155, Tadiran TL-4955, Tadiran TL-5155, Tadiran TL-5955
- Xeno XL-055F,SL361,TL4955,XL055H
Warning:
- This battery is not rechargeable. Do not try to recharge.
- The storage area should be clean, cool (not exceeding +30 Deg C ), dry and ventilated
- Please discharge the battery few minutes with 100mA,if the battery voltage is lower than your need or consult ABLE.
- Don't use different models of battery in series.
- Soldering the tab should be finished in few seconds.
- Do not use if the battery casing was mangled
|
