製品情報
| 原産地: 中国(本土) | 銘柄: TH | モデル番号: TH-24V20AH |
| 構成されたタイプ: 組み合い | タイプ: 李イオン | 部品: マンカ、三元 |
| サイズ: オ-ダ-メイドできる | 電圧: 24V | 重量: 約4.5KG |
| わずかな容量: 20AH | 適用: 電動バイク、電動工具、蓄電池 | 色: 青い |
| 保証期間: 2年間 |
包装
| 包装: プラスチックケ-ス付きできる,パッケ-ジ：段ボ-ル箱 |
Features
1. Low self-discharging: less than 10%/month, and no"remember benefit".
2. Long durability: it can be used for more than 600 cycles.
3. Safety function: polymer Li-ion battery use the soft package and does not contain liquid electrolyte, so its safety function is well enough that will not be harmful to people.
4. No pollution: the battery does not contain any harmful matetrial, so it is absolutely friendly to environment, it is a kind of green energy
5.Unique aluminium alloy case with light weight, so that it can reduce the weight of E-bike
Specifications
1.Basic Characteristics | ||
Product Model | TH-24V/20Ah | |
Nominal Voltage | 24V | |
Nominal Capacity | ≥20AH | |
Discharge end voltage | 21V | |
Charge protect voltage | 29.4V | |
Max charge voltage | 29.4V | |
Max charge current | 10A | |
Max discharge current | 40A | |
Nominal discharge current | 20A | |
Charge mode | CC/CV | |
Working temperature | Charge | 0~50°C |
Discharge | -20~60°C | |
Storage temperature( 60-80%SOC storage,need charge once every 2 months.) | -10~40°C | |
Cycle life | 600 times(Normal temperature ,1C cycle to 60%,100%DOD) | |
2.Safety certificate: CE ROHS UN38.3 | ||
