製品情報
原産地: 中国(本土) | 銘柄: LEADHOO | モデル番号: NP12-12 |
使用法: UPS | 電圧: 12v | 密封されたタイプ: 密封される |
維持のタイプ: 自由 | サイズ: 150*98*95mm | 重量: 3.4kg |
わずかな容量: 12ah |
包装
包装: 標準エクスポート パッケージ ペーパー ボックス パッケージ |
LEADHOO 鉛酸バッテリー 12V12AH:
アプリケーション:
1.警報システム
2.UPS
3.アクセスコントロール機器
4.セキュリティシステム
5.緊急電力供給システム
6.子供のおもちゃ
7.コミュニケーション機器
8.医療機器
詳しい製品の説明: |
仕様 |
Nominal Voltage | 12 V | |||
Rated Capacity (20 hour rate) | 12AH | |||
Dimensions(Length*Width*Height*Total Height )/mm | 150×98×95mm | |||
Weight Approx | 3.40kg | |||
CHARACTERIESTICS | ||||
Capacity25℃ | 20 Hour rate (0.35 A) | 12.0AH | ||
10 Hour rate (0.64 A) | 11.0AH | |||
5 Hour rate (1.20 A) | 10.2AH | |||
1 Hour rate (4.20 A) | 7.20AH | |||
1.5 Hour discharge to 10.5V | 4.8A | |||
Internal Resistance | Fully charged battery at 25℃ | 16m Ω | ||
Capacity affected by temperature(20 hour rate) | 40℃ 25℃ 0℃ -15℃ | 102% 100% 85% 65% | ||
Self-DischargeAt 25℃ | Capacity after 3 month storage Capacity after 6 month storage Capacity after 12 month storage | 91% 82% 64% | ||
Terminal Type | T2 | |||
Charge(Constant Voltage) | Cycle use | Initial Charging Current less than 4.80A Voltage14.40~15.00V Time 14~16h | ||
Float use | Voltage 13.50~13.80V | |||
Place of Origin: | Shenzhen in China | |||
Model No: | 12V12AH | |||
Brand Name: | Leadhoo |
