製品情報
| 原産地: 中国(本土) | 銘柄: トップ | モデル番号: Bdv-iij |
| 色: 必要に応じて |
包装
| 包装: 木製ケース |
仕様
絶縁油分析中デバイス1.高い精度と抗- 干渉2.iec標準を満たす1563.varible電圧
TOP auto oil analysing device for insulation oil,60/80/100kV, store 99 groups of test record, with printer, LCD display
Application:
Automatic Breakdown Voltage Tester of Testing Insulation Oil is produced as per the newest international standards
such as ASTM D1816, IEC156, ASTM D899, etc.
which adopts industrial single plate integrated circuit, new-style I/O ports,
with unique inspection and anti-jamming technology to greatly improve its reliability and functionality.
Features :
1) Fully automatic, control by microcomputer, utilization of new I/O terminal.
2) Numbers of times of testing and idling time of stirring are set via digital setting.
3) Test results displayed and printed out automatically.
4) Strong capability of anti-interference.
5) High accuracy of testing and high capacity of anti-jamming.
6) Easy to operate, small size, light weight which operated in the open air very conveniently and convenient for maintenance
7) Can store 99 groups oil testing data which is convenient to reading and print.
The testing data can keep 100 years under the condition of power off.
8) System time can go on running under power off.(the system time just for reference can not be the standard of timing)
the system time just for reference can not be the standard of timing)
1.Can upgrade software through RS232
2.High capacity of anti-jamming and high precision of testing.
3.Small volume, light which operated in the open air very conveniently.
Technology and parameter data
Technical Parameters:
Power supply | AC220V±10%,50Hz |
Output voltage | 0~80KV(60KV,80KV) |
Capacity | 1.2KVA(1.6KVA,2.0KVA) |
Speed of pressure rise | about 2KV/S |
Voltage test precision | ±3% |
Breakdown sensitivity | <2KV |
Wave difference | ≤3% |
Time of breakdown | ≤10ms |
Working - temperature | 0~40 |
- humidity | The biggest comparatively humidity85% |
Reserve circumstance- temperature | -20~60 |
- humidity | The biggest comparatively humidity75% |
- Working altitude | <1500m (if over 1500m can be designed specially) |
Dimension | 480mm*460mm*460mm |
Kinds of industrial oil purifier product list we can offer:
1: Insulating oil purifier
1-1: Single stage vacuum insualtion oil purifier
Series ZY: TOP vacuum insulation oil purifier
Series ZY-A: TOP PLC type automatic vacuum insulation oil purifier
Series ZYB: TOP vacuum insulation oil regeneration purifier
Series ZY-W: TOP weatherproof enclosed type vacuum insulation oil purifier
Series ZY-M: TOP Mobile trailer type vacuum insualtion oil purifier
1-2: Double stage vacuum transformer oil purifier
Series ZYD: TOP Double-stage vacuum transformer oil purifier
Series ZYD-A: TOP PLC type double-stage vacuum transformer oil purifier
Series ZYD-I: TOP double-stage vacuum insulation oil regeneration purifier
Series ZYD-W: TOP Enclosed type double stage vacuum transformer oil purifier
Series ZYD-M: TOP Mobile trailer type online transformer oil purification plant
2: Turbine oil purifier
Series TY: TOP vacuum turbine oil purifier
Series TY-R: TOP vacuum turbine oil regeneration purifier
Series TY-A: TOP PLC type automatic vacuum turbine oil purifier
Series TY-W: TOP weather proof enclosed type vacuum turbine oil purifier
Series TY-M: TOP mobile trailer type vacuum turbine oil purifier
3: Lubricating oil purifier
Series TYA: TOP vacuum lubricating oil purifier
Series TYC: TOP vacuum lubricating oil regeneration purifier
Series TYA-A TOP PLC type automatic vacuum lubricant oil purifier
Series TYA-I: TOP vacuum phosphate ester fire-resistant oil purifier
Series TYA-W: TOP weatherproof enclosed type vacuum lubricant oil purifier
Series TYA-M: TOP mobile trailer type vacuum lubricant oil purifier
4: Special application oil purifier
Diesel oil, gasoline oil and fuel oil purifier Series TYB
Transformer oil regeneration device Series BZ
Muti-Functional oil purifying machine Series ZYB
PL Plate pressure high precise oil purifier
JL Portable oil purifying and oil filling machine
TYF Fully stainless steel type vacuum oil purifier
Series EOR Engine oil recycling distillation system
Other Search Key Words:
Vacuum Oil Purifier, Industrial lubricant Oil Filtration, Hydraulic Oil Cleaning, Gear-box Oil Recycling, Compressor Oil Filtering Plant, Coolant Oil Treatment Machine, Diesel Oil Purification,
Oil Regeneration, Oil Purifying Plant , Transformer Oil Filtration System,
Insulating Oil Treatment Machine, Dielectric Oil Reconditioning Machine, Oil Regeneration, Oil Restoration, Oil Reprocessing,
Transformer Oil Purification System, Oil Flushing Equipment, Vacuum Oil Dehydration and Degasification Unit
if you are iterested in our products ,please contact us and we will reply you as soon as possible
