製品情報
| 原産地: 中国(本土) | 銘柄: huakeyi | モデル番号: Dws-51 |
仕様
Dws-51ベンチ- トップナトリウムイオンアナライザベンチ- トップナトリウム計ラボ使用のための、 水質分析用。
DWS-51 Bench-top Sodium Ion Analyzer
Manufacturer
Beijing Huakeyi Power Plant Instrument Research Institute
Features
Ø SMT AND INTEGRATIVE DESIGN Enhance performance and reliability
Ø UNIQUE SODIUM-SENTIVE ELECTRODE AND REFERENCE ELECTRODE---- Ensure accurate and fast measurement
Ø TEMPERATURE COMPENSATION Auto or manual
Ø INTELLIGENT AUTO MEASUREMENT JUDGE STABLE FUNCTION ---Make operation convenience
Specifications
TRANSMITTER | |
Display | LED |
Measurement Range | (0.00~9.36) pNa, 0.1μg/L~9999mg/L |
Resolution (min) | 0.01pNa or 0.01μg/L |
Accuracy | ±0.02pNa or one character (between ±10oC of calibration temperature) |
Stability | ±0.01pNa/4h |
Input Impedance | ≥1×1012Ω |
Temperature Range | (0.0~60.0)oC |
Temperature Accuracy | ±0.2oC |
Temperature Resolution | 0.1oC |
INSTRUMENT | |
Measurement Range | (1.00~8.00 )pNa,0.2μg/L~2300mg/L |
Response Time (T90) | ≤2 min at 25oC |
Temperature Sensor | Pt1000 |
Temperature Range | (0.0~60.0)oC |
Temperature Accuracy | ±0.5oC |
Temperature Measuring Resolution | 0.1oC |
Temperature Compensation | (0.1~60.0)oC (auto or manual) |
Sample Temperature | (5~60)oC |
Ambient Temperature | (5~45)oC |
Ambient Humidity | ≤90%RH (no condensation) |
Storage Temperature | (-25~55)oC (above 0oC for pH electrode) |
Power Supply | (220±22)VAC, (50±1)Hz |
Power Consumption | ≤3w |
Overall Dimension (mm) | 200(L) × 210(W) × 65(H) |
Weight | 2kg |
Standard Package
· 1 × Analyzer (03.02.06)
· 1 × Sodium electrode (HK-5101S) (01.05.04.07)
· 1 × Reference electrode (HK-5102S) (04.02.42)
· 1 × ATC temperature sensor (04.02.01)
· 1 × Electrode bracket
· 1 × Electrode holder (01.05.05.02)
· 1 bottle of electrolyte for reference electrode (60ml) (04.06.02)
· 1 bottle of reactive solution (60ml) (04.06.03)
· 2 bottles of standard solution (20mg/L, 200mg/L) (04.06.01)
· 2 × Plastic beaker (100ml) (01.10.03.01.02)
