製品情報
| タイプ: エスカレーター | 原産地: 中国(本土) | 銘柄: deao |
| モデル番号: De-30/35 | 名: 屋内エスカレータや動く歩道を | moq: 1セット |
| 定格速度: 0.5m/s | 角度: 30度または35度 | ステップ幅: 600mm、 1000mm800ミリメートルまたは |
| 駆動システム: vvvf |
包装
| 包装: 標準的な輸出パッキング |
仕様
屋内エスカレータや動く歩道を: 1.先進的なvvvf駆動2.30度または35度自動エスカレーター
Product Description
Indoor escalators and moving walks
1. Techinical Datas:
30° Escalator construction dimensions
| |||||||||
Model | Traveling height H (mm) | Motor Power(kw) | Rate speed(m/s) | Max. delivery capacity(p/h) | Inclination
| Step width(mm) | Handrail center distance(mm) | Escalator outside width(mm) | Installation width(mm) |
DE(600/30°)
| 3000≤H≤5000 | 5.5 | 0.5
| 3600
| 30 | 600
| 838 | 1200 | ≥1260 |
5000<H≤6000 | 8 | ||||||||
DE (800/30°) | 3000≤H≤4000 | 5.5 | 0.5 | 4800 | 30
| 800 | 1038 | 1400 | ≥1460 |
4000<H≤5500 | 8 | ||||||||
5500<H≤6000 | 11 | ||||||||
DE (1000/30°) | 3000≤H≤3500 | 5.5 | 0.5 | 6000 | 30
| 1000 | 1238 | 1600 | ≥1660 |
3500<H≤4500 | 8 | ||||||||
4500<H≤6000 | 11 | ||||||||
35° Escalator construction dimensions
| |||||||||
Model | Traveling height H (mm) | Motor Power(kw) | Rate speed(m/s) | Max. delivery capacity(p/h) | Inclination
| Step width(mm) | Handrail center distance(mm) | Escalator outside width(mm) | Installation width(mm) |
DE(600/35°)
| 3000≤H≤4500 | 5.5 | 0.5
| 3600
| 35 | 600
| 838 | 1200 | ≥1260 |
4500<H≤6000 | 8 | ||||||||
DE (800/35°) | 3000≤H≤4000 | 5.5 | 0.5 | 4800 | 35
| 800 | 1038 | 1400 | ≥1460 |
4000<H≤5000 | 8 | ||||||||
5000<H≤6000 | 11 | ||||||||
DE (1000/35°) | 3000≤H≤3500 | 5.5 | 0.5 | 6000 | 35
| 1000 | 1238 | 1600 | ≥1660 |
3500<H≤4500 | 8 | ||||||||
4500<H≤6000 | 11 | ||||||||
2. Specifications:
Specifications | |||
| Angle | 30 degree or 35 degree | ||
| Operation system | PLC control or VVVF control | ||
| Speed | 0.5M/S | ||
| Step width | 600mm, 800mm, 1000mm | ||
| Step Material | Stainless steel or aluminum | ||
| Handrail | Rubber (black) + 10mm tempered glass | ||
| Inter and outer cover plate | Stainless steel | ||
| Demarcation lamp | Yes | ||
| Power supply | As your request | ||
| Inverter | Simplex full collective selecive VVVF close loop(M0NARCH) | ||
| Decoration | Use stainless steel or use painted aluminum for outside cladding | ||
| Standard features | |||
| 1, Manual oiling 2, Built-in chain roller step 3, Inclined handrail | |||
| 4, Demarcation lamp 5, Handrail inlet 6, Table type traction machine | |||
| Optional features | |||
| 1, Running direction indication 2, Handrail illumination 3, EHC colorful handrail | |||
| 4, VVVF controller 5, Skirt panel brush 6, Automatic start & stop 7, Automatic oiling | |||
| Packing(Waterproofing foil) | |||
Workshop
Certifications
FAQ
GENERAL BUSINESS FAQ:
1. Regarding any inquiry from Alibaba, DEAO will provide you the prompt feedback and professional solution/quotation within 24 hours.
2. All above specifications are based on DEAO Elevator Co., Ltd. standard configuration and only for equipment price which does not include adjustment, assembling after goods arrived at the destination/customer's jobsite.
3. Terms of payment: 30% down payment by TT within 7 days after order released to DEAO Elevator Co., Ltd., balanced by T/T or L/C before shipment.
4. Guarantee:The quality guarantee is 12 months after the delivery.
5. Quotation validity: One month since the date of release.
6. Regarding the installation&maintaining,our sugguestion is to hire a professional local company for installation and future maintaining,once you need any technical assistant from us, just don't hesitate to contact us by mail or phone.Technician will be sent to the job site if necessary.
