製品情報
| 原産地: 中国(本土) | 銘柄: kingeda | モデル番号: hd100 |
仕様
簡単に更新する、 コストパフォーマンスの高い多くの方法で広範なアプリケーション高い安定性、 連続して動作し7x24h止められない
HMID Video Capture Card Apllication in medical field
Interface |
|
Host Interface | PCI-Express x1, Low Profile, 200MB/s tranmission bandwidth |
Input Interface | 1 HDMI interface (connect to DVI signal) |
DVI Video Input | 1 1080p/60HZ HD DVI signal |
HDMI Video Input | 1 1080p/60HZ HD HDMI signal |
YPbPr Video Input | 1 YPbPr signal |
S-Video Input | 1 SD S-Video signal |
CVBS Video Input | 1 SD video signal |
HDMI Audio Input | 1 LPCM audio signal |
Analog Audio Input | 1 analog audio signal |
Signal Standards |
|
| |
DVI Input Format | It meets the standard of DVI 1.0 and single connection (480i, 576i, 480p, 576p, 720p, 1080i, 1080p) |
| |
HDMI Input Format | It meets the standard of HDMI 1.3, and support 36 bits DeepColor |
| |
YPbPr Input Format | 480i, 576i, 480p, 576p, 720p, 1080i, 1080p |
| |
CVBS Input Standard | PAL/NTSC |
| |
HD Output Formates | 40×30-2048×1536, frame rate: 1-100 fps |
| |
SD Output Formats | 176×144-768×576, frame rate: 1-30 fps |
| |
Analog Audio Sampling Rate and SNR | Up to 96KHz, 85db, 24 bits |
| |
Video Sampling Rate | CVBS: 57.27MHz (4x Oversampling) RGB/ YPbPr: 170MHz HDMI/ DVI: 225MHz |
| |
Video Sampling Precision Rate | 10 bits | ||
Video Processing |
|
Color Space Switch | Hardware Color Switch |
De-interlacing | Vertical filter de-interlacing; motion-adaptive de-interlacing |
Image Scale | Hardware 5-Tap Scale |
Image Mirror | Horizontal; vertical |
Image Clip | Yes |
Image Adjustment | Horizontal; vertical saturation adjustment/control of monochrome and color |
Application |
|
OS Support | Support the following operating systerms, including x86 and x64: |
Software Compatibility | Windows Media Encoder |
onboard Memory | 128 MB DDR2, working rate is 160 Mhz, bit width is 32 bits |
Upgrade | Firmware can be upgraded |
Installation | Inserted in PCI-Express x1, x4, x8 or x16 slot, and installed in 2U chassis or 4U chassis |
Size | 99mm x 69mm |
Power Consumption | <= 4W |
Warranty | 1 Year warranty |
High Resolution standard 1080P/60Hz
HD Signal 1080P can be captured at 60Hz : the resolution can be as high as 2 Mega Pixels (1920*1080) at 60fps realtime live displaying. That brings you top experience of HD video and audio.
