製品情報
| 原産地: 中国(本土) | 銘柄: younio | モデル番号: LXSG-15E1 |
包装
| 包装: In standard box or carton! |
仕様
magnetic,dry type,with a pair of connectors,ISO 4064 Class B
Features:
Dry-dial,magnetic drive,protected against external magnetic tampering
Vacuum sealed register,frost resistant,keeps clear reading for lon time
Brass body
Body can be painted
For cold water
ISO 4064 :1993 Class B
ISO 4064:2005 R80/R100
Working condition:
Water temperature 50°c
Water pressure≤1MPa
(PN:1.6MPa/16bar)
ΔP≤0.1MPa(Class B/)
ΔP≤0.063MPa(R80/R100)
Accuracy:
From minimum flow-rate(qmin/q1)inclusive, to transitional flow-rate(qt/q2),exclusive:±5%
From transitional flow-rate (qt/q2)inclusive,to overload flow-rate(qs/q4),exclusive::±2%
Technical data:
| DN/Q | Q4=1.25Q3 Q3 | R=Q3/Q1 | Q2=1.6Q1 Q1 | R=Q3/Q1 | Q2=1.6Q1 Q1 |
| l/h | l/h | l/h | |||
| 15 | 3125 2500 | 80 | 50 31.25 | 100 | 40 25 |
| Nominal size DN(mm) | Class of measurement | Oveload flow-rate qs(m3/h) | Permanent flow-rate qp(m3/h) | Transitional flow-rate qt(l/h) | Minimum flow-rate qmin(l/h) |
| 15 | B | 3 | 1.5 | 120 | 30 |
Overall dimensions and weight:
| Type | Size(mm) | Length(mm) L | Width(mm) W | Height(mm) H | Connecting Thread D | Weight(kg) |
| LXSG-15E1 | 15 | 165 | 99 | 104 | G3/4"B | 1.5 |
