製品情報
銘柄: パワーlvhuan | モデル番号: lhstg10 | 原産地: 中国(本土) |
適用: 調理用燃料 | カロリー(J): 42000 | メタン含有量 (%): 40 |
バイオガス: バイオガス発電機2000シリーズ |
包装
包装: 耐航性のあるパッケージ |
仕様
アイテム: バイオマス発電機のパワー: 100キロワット; 50キロワット; 150キロワット、 350キロワット、 400kw、 500kw、 600キロワット周波数: 50hzi soandセリウムの証明書
Model number ( engine type) | lhstg10 |
Brand name | lvhuan |
Prime power/standby power | 8kw/10kw |
Rated speed | 1500/1800rpm |
Rated frequency | 50/60hz |
Rated voltage | 400v/230v |
相 | Ac 3- 相、 4 wire |
Voltage stability | ・ル;& plusmn; 2% |
Voltage transient | ・ル;& plusmn; 10% |
Voltage stable time | ・ル; 1s |
Heat consumption | ・ル; 9.8mj/kw。 h |
Lubricant consumption | ・ル; 1.63g/kw。 h |
Engine capacity | 2.24 l |
Cylinder number | 2 |
Cylinder bore | 100mm |
ストローク | 115ミリメートル |
Starting system | Dc 24v electric motor |
Cooling method | Water cooler |
Lubricant method | Passive and flying lubricant |
タイプ | Four stroke、 water cooled、 turbocharged and aftercooled、 spark plug ignition |
Isolation class | h |
保護 | ip23 |
オルタネータ | Chinese stamford |
Power factor | 0.8 lagging |
Exciting method | Brushless |
色 | Your choice |
証明書 | Iso 9001:2008、 ce |
保証 | 1 year or 1500 running hours which arrives first |
Compression ratio | 10:1 |
Control system | Automatic alarm system |
サイズ | 1450700x1100mm |
重量 | 700kg |
