製品情報
| 原産地: 中国(本土) | 銘柄: Yuan | モデル番号: YA-600P |
包装
| 包装: 木製ケースに詰め,内側のダンボール箱に梱包 |
Specifications
Ticket dispenser housing
equiped with RFID reader, card dispensing machine
available with voice prompt, words displayer
Card dispensing machine(Parking system)
Recycling smart card
l Recycles more than than 100,000 times
l Reads and Encodes parking information on card with contact-less
l Erases printed parking information on card by Ticket Eraser
l Stores about 150-500 IC or ID cards
Main function
l Installed at the entrance with electric barrier, and issues hourly tickets to incoming drivers.
l Encodes date/time, serial number, unit number and parking number on card.
l When the unit reads season card, year card, park value card, and temporary card, and then the electric barrier(e.g. YA-609D) opens.
l When the parking lot is full, ticket-issuing is stopped and the full sign appears.
l An intercom and a call button are provided for the user to contact the managing office.
Available option
l Housing material: Iron baking paint, stainless steel
l Useful guidance: Voice guidance, LED words diplayer, for incoming driver
l Card handling: RF season card, Contact-less debit card, VIP card.
l External display: Car number displayer, vacancy displayer
l Image management: Image management system, Vehicle license recognition system
l Main power: AC220V+(-)10% 50Hz or AC110V+(-)10% 60Hz
l Issuing speed: Within 2 seconds
Main specification:
l Dimension: L460*W440*H1290(mm)
l Operating temp. -10°C---+55°C(Incase of Temp. compensate: -30°C-65°C)
l Power consumption: Approx. 70W
