製品情報
| 原産地: 中国(本土) | 銘柄: -- | モデル番号: LC-11 |
| 力: 501-1000w | 電圧: 48v | 証明: EEC |
| 充満時間: 6-8h | Foldable: はい | 充満ごとの範囲: 60-80km |
| タイヤサイズ: -- |
包装
| 包装: Carton and Iron fra-me |
仕様
Motor Type Brushless DC Motor Gyroscope quantities 3 units Battery Capacity 70V 14Ah Lithium Ion battery
Electric Mobility Scooter( LC-11)
| Maximum motor power | 700w | ||
| Motor Type | Brushless DC Motor | ||
| Gyroscope quantities | 3 units | ||
| Battery Capacity | 24V Lithium Ion battery | ||
| Operating Range | 1 battery pack range = 27Km (16.75 Miles) / 3hours. | ||
| 2 battery packs range = 54Km (33.5 Miles) / 7hours. | |||
| Mileage / Range ( Max Range of Single charger) | 27Km (16.75 Miles) | ||
| Maximum Speed | 20 Kilometers per hour (11.25 Miles per hour) | ||
| Charging time | 4 hours | ||
| Balance mode | Inertial navigation module | ||
| Display functions | LED Meter Display function. Mileage, speed, timer, options of speed,vibration alert, the battery level, Over speed limiting, over load protection | ||
| Loading capacity | 35-100 Kgs (77 - 220 lbs) | ||
| Maximum Gradient | 26 degrees | ||
| Tyre Size | 100/65-14 (Outside Dia 47cm 18.5 Inches) | ||
| The vehicle weight | 47 Kg/single battery unit (104 lbs) | ||
| Overall dimensions | 520 x 550 x 650 (20.4" x 21.7" x 25.6") | ||
| packaging Size | 580 x 600 x 700 (22.85" x 21.7" x 25.6") | ||
| Loading capacity 1x20GP' | 80 units | ||
| Lithium battery quotation | If you choose to assemble 2 units lithium battery . It should be add US$267/unit ( 70V14A ) | ||
| The charger | from 110V to 220V. 50HZ or 60HZ. Could be adjusted. | ||
| Feet Pedals Switch function | all model has this function. ( when your feet stand on the scooter, the scooter will start to go, when your feet down from the scooter, scooter will stop immediately) ) | ||
| color | Black, purchase order color could be white,red, yellow,blue. Etc. | ||
| Fold | It could be foled if order quantity above 10 units. The standard is not fold. it will add $ 10/unit for folding | ||
| Spare parts | 1% free of charge based on above 30 units order quantity. | ||
| Warranty | one year, Lithium battery 2 years. Including motor, computer program, not including easy dameged spare parts. If spare parts quality problem, we will ship free charge spare parts during 7 days by air. | ||
| Terms of Payment | T/T ( bank to bank ) ; Paypal ; Western unio Escrow ( Europe, USD,RMB ) | ||
| Delivery time | Sample 7-10 days; purchase quantity: 20 -30 days | ||
| Shipping Ways | By air DHL( door to door ) ; By sea | ||
