製品情報
適用: レーザーの彫版 | 条件: 新しい | レーザーのタイプ: 二酸化炭素 |
彫版区域: 1200*900mm | 彫版の速度: 0-50000mm/min | CNCまたはない: はい |
冷却モード: 水冷却 | 適当な材料: アクリル, Crytal, ガラス, 革, MDF, 金属, ペーパー, プラスチック, Plexiglax, 合板, ゴム, 石, 木 | 支えられる写実的なフォーマット: AI, PLT, DXF, BMP, DST, DWG, LAS |
原産地: 中国(本土) | 銘柄: ロデオ | モデル番号: Rd-1290 |
次元(L*W*H): 1360*1110*820mm | 証明: セリウム, ISO | 提供される売り上げ後のサービス: 利用できるエンジニア機械類を海外に整備するため |
レーザーチューブの電源: 80w/100w/130w/150w | 最大の切削速度: 0から30、 000mm/min | レーザー出力制御: 1-100%ソフトウェアの設定 |
位置の精度: 0.01mm以下 | 冷却モード: 水- 冷却と保護システム |
包装
包装: 標準の合板のコンテナ |
仕様
レーザー切断機2頭1.ブランドレーザーreciチューブ2.台湾pmiガイドレール正方形3.transmissベルト
火星シリーズrd-14902頭co2アクリル 木材レーザー切断機の価格
1.特徴:
1)。 equipped with imp0rted dual linear guide、 so machine can move stably and cut the edge smoothly
2)。 adopt three- phase motor and driver、 belt can move in fast cutting speed and high precision。
3)。 advanced control system: advanced dsp numerical control systm and laserge liquid crystal display brings out much convenient operation and simpler maintenance。 special intelligent pre- calculating system fully develops the potential of the engine and leads to high speed processing of smoother curves and straight lines simultaneously。
4)。 powerful compatibility: internationalized directives ensure that it is compatible with cad/cam software like type3/ artcam/ castmate/ proe/ ug/ artcut etc。 home and abroad。
5)。 off- line control system: apply usb interface to communicate with computer under the system of win98/nt2000/xp、 which can instantly compete transmission。
2.applicable industries:
Advantisement、 arts and crafts、 shoes、 toy、 garments、 model、 construction industry and so on。
3.applicable materials:
非- me-tal materials such as double color boards、 acrylic、 glass、 crystal、 wood、 foam、 bamboo、 rubber、 plastic、 garments、 paper、 leather、 marble、 granite、 tiles and etc。。
4.オプション:
1) motorized up・down platform
2) rotary attachment
3) chiller( cw- 5000 or cw- 3000)
4) auto focus
5) ccd for logo/lable
6) filter
5.仕様:
1) | レーザー- タイプ | Sealed co2 laser tube、 water- 冷却、 10.6um |
2) | Laser tube of power | 80w/100w/130w/150w |
3) | Working area | 1200 x900mm |
4) | Max moving speed | 0から60、 000mm/min |
5) | Max cutting speed | 0から30、 000mm/min |
6) | Laser output control | 1-100% software setting |
7) | Location precision | Less than 0.01mm |
8) | Highest scanning | 精度: 2500dpi |
9) | 動作 | 温度: 0- 45 degrees celsius |
10) | Operating humidity | 5- 95% |
11) | minimum shaping character | English 1.0 x 1.0ミリメートル、 chinese 2.0x2.0mm |
12) | Graphic format supported | Bmp、 plt、 dst、 dxf、 and ai |
13) | Driving system | Stepper |
14) | Cooling mode | ウォーター- cooling and protection system |
15) | Auxiliary equipments | 排気- ファン、 air- exhaust pipe、 water pump |
16) | Controlling software | Dsp control system。 |
17) | Compatible software | Tajima 、 coreldraw、 autocad、 photoshop |
18) | Color separation | はい |
picture:
Guarantee ・ after- sales service
、。 One year warranty under normal use and we give maintenance for life for free。
B。 24hours technical support by phone、 e- mail or msn or remote assistance。
C。 free training to make sure you master the operation of cnc router
