製品情報
| 条件: 新しい | 原産地: 中国(本土) | 銘柄: auston |
| モデル番号: zp17d | タイプ: 回転式タブレットの出版物 | 製品容量: 40、 000pcs/hr |
| 最高。 圧力(KN): 60kn | 最高。 タブレットの厚さ(mm): 6mm | 最高。 タブレットの直径(mm): 20mm |
| 電圧: 380v/220v | 力(W): 2.2キロワット | 重量: 千キロ |
| 次元(L*W*H): ××6158901,415ミリメートル | 材料: ss304 |
包装
| 包装: 標準的な輸出木製ケース |
仕様
1.製薬ロータリー打錠機2.フル- enlosed小さなロータリー打錠機3.gmp・ce
Characteristic:
1.The outside part of the machine is fully-enclosed, and it is made of stainless steel,meeting the GMP requirement
2.It has transparent windows so that press condition can be observed clearly and the windows can be opened. Cleaning and maintenance is easier
3.The machine can press not only round tablets but also different geometrical shape tablets, double-layered and annular tablets, the tablets may have the impressed letters on both sides
4.All the controllers and devices are located in one side of the machine, so that it can be easier to operate
5.An overload protection unit is included in the system to avoid the damage of the punches and apparatus, when overload occurs
6.The machine's worm gear drive adopts fully-enclosed oil-immersed lubrication with long service-life, preventing cross pollution
Main technical data:
Dies | 17 sets |
Max. pressure | 60kN |
Max. dia. of tablet | 20mm |
Max. depth of fill | 15mm |
Max. thickness of tablet | 6mm |
Turret speed | 37r/min |
Production capacity | 40,000pcs/h |
Motor | 2.2kW, 940r/min, 380/50V/Hz |
Overall size | 615 x 890 x 1,415mm |
Net weight | 1,000kg |
