製品情報
| 条件: 新しい | CNCまたはない: 正常 | 原産地: 中国(本土) |
| 銘柄: J | モデル番号: Z5050A | ビジネスタイプ: 製造業者 |
包装
| 包装: 木製の包装 |
仕様
Z5050Aの縦の鋭い機械1)最高の訓練dia. 50mm 2)最高の叩くdia M24 3の)テーブルのサイズ: 370*500MM
Specifications | Units | Z5040A | Z5050A |
Max drilling dia. | mm | 40 | 50 |
Max Tapping dia | mm | M24 | M24 |
Distance between spindle axis and column | mm | 360 | 360 |
Distance between spindle nose and worktable surface | mm | 600 | 600 |
Distance between spindle nose and base plate | mm | 1215 | 1205 |
Max Spindle traverse | mm | 180 | 180 |
Max adjustment of worktable and table rest | mm | 560 | 525 |
Spindle bore taper | Morse No. | 4 | 4 |
Swivel of table and table rest |
| ±45° | ±45° |
Range of spindle speeds | rpm | 42-2050 | 42-1865 |
Number of spindle speeds | step | 12 | 12 |
Range of spindle feeds | mm/r | 0.07,0.15,0.26,0.4 | 0.07,0.15,0.26,0.4 |
Column dia | mm | 160 | 170 |
Table size | mm | 370*500 | 370*500 |
Motor power | kw | 2.2/2.8 | 2.2/2.8 |
AC power input | V | 220,380,420,440 | 220,380,420,440 |
Net weight | kg | 740 | 800 |
Overall dimensions (L/W/H) | cm | 70*115*215 | 70*115*215 |
