製品情報
| 原産地: 中国(本土) | 銘柄: liangyou | モデル番号: dk7750a |
| 条件: 新しい | 色: 緑、 白またはとしてorderdに | 用法: スレッドの加工機 |
| モードを制御する: cnc | 精度: 高精度 | 加工タイプ: 金属 |
| 自動グレード: 自動 | 工作物と重量: 重い- デューティーマシンツール | 加工: edm |
| ブランド名: liangyou | モデル: dk7750a |
包装
| 包装: dk7750aedmワイヤカット機価格利用長距離輸送のため耐航性のあるパッキング |
仕様
Edmワイヤカット機価格dk7750a1.高速2.高精度3.良い品質
DK7750A edm wire cutting machine price
Product Descri-ption
| The main parameters | Model | |
| DK7750A | DK7750A Taper | |
| Max.table travel(mm) | 630×500 | 630×500 |
| Worktable size(mm) | 830×520 | 830×520 |
| wire travel length(mm) | 220~630 | 180~545 |
| Max. workpiece thickness(mm) | 600 | 515 |
| Wire diameter(mm) | Φ0.12~0.22 | Φ0.12~0.22 |
| Max.processing efficiency (mm2/min) | 180 | 180 |
| Roughnes Ra/μm | 1.25~2.5 | 1.25~2.5 |
| Power consumption(kw) | 1.8 | 1.8 |
| Max wire length(m) | 320 | 320 |
| Max. wire speed(m/s) | 11 | 11 |
| load of worktable(kg) | 450 | 450 |
| Machine weight(kg) | 1700 | 1700 |
| Machine dimensions(mm) | 1880×1490×1760 | 1880×1490×1760 |
| Taper | ±5° | |
(1) The machines characteristics
1. Make features of big taper, considerable thickness, high efficiency, high precision and new structure etc, lead this industry;
2. There are computer, machine electric and pulse power supply all in the controller;
3. Main computer has two kinds of typessingle board computer and microcomputer;
4. Double CPUs structure in microcomputer, program and control at the same time;
5. Good rigidity, running placidly, strong function, convenient and reliable operation;
6. The whole closed machine bed, working table with T shaped groove, pane fixture;
7. Suitable to process conductive me-tal moulds, complex me-tal parts and templates with high precision, high toughness and difficult processing;
8. Can cut plane, bevel, top and bottom different shaped surface, greatly expand the processing range;
9. According to users request, add half closed-loop, transducer control system.
(2) Main performance indexes and technical requirements
1. Software basic functions
A. Coordinate system: absolute coordinate, incremental coordinate (relative coordinate);
B. Functions of coordinate transforming, zooming in and zooming out, rotating and tracking display in real time;
C. Functions of interpolation of straight line and circular arc;
D. Function of taper processing;
E. Function of processing different top and bottom shape;
F. Functions of short circuit and wire-break handling;
G. Functions of memorizing when power was cut and auto-stop after processing;
H. Functions of auto-edge position and auto-centering;
I . Function of auto-adding transitional arc (Arbitrary angle);
J. Function of processing backward;
K. Functions of menu technology and auto-programming;
L. Data transmission.
Optional Controller
C08-Single Board Computer Controllor
C08-Microcomputer Controllor
