製品情報
| 原産地: 中国(本土) | 銘柄: LONKING | モデル番号: LG855D |
| 提供される売り上げ後のサービス: 提供される海外サービス無し | Mental: yellow |
包装
| 包装: by nude |
LONKING Wheel loader LG855D new loader (3.0m3, 5ton payload)
Specifications
Bucket Capacity: 3.0m3
Rated Payload: 5000kg
Operating Weight: 16600kg
Engine Power: 154kw
Max.Dumping Height: 3103mm
new loader
Weichai WD10G240E21 engine
(Low-speed engine 1900rpm).
--The transmission quanlity stablel.
The international the most famous engine such as komatsu ,Volvo enigne
the low speed engine 1800rpm. and our lonking now is 1900rpm, other brand may 2200rpm)
So it can Save 15% fuel. Low noise. Low wear mantainance cost.
Optional attachments:
Joy Sitck ( long arm : the lift height : 3.53m)
Air Conditioner A/C
Quick Hitch
Grass-grasping (for catching the grass)
Log fork ( for catching the wood)
Side lift bucket ( The bucket can work left and right , for the working in the tunnel )
Overall Data |
| Steering System |
| |||||||||||||
Bucket Capacity (m3) | 3.0 | Type | Hydraulic Load Sensor System |
| ||||||||||||
Rated Payload(kg) | 5000 | Cylinders-Bore× Stroke(mm) | 2-100×324 |
| ||||||||||||
Operating Weight(kg) | 16600 | Steering Pump | Gear Pump |
| ||||||||||||
Traction Force(kN) | 155±3 | System Pressure(M Pa) | 15 |
| ||||||||||||
Breakout Force(kN) Max.Dumping Height (mm) | ≥170 3103 | Flow Rate(L/min/rpm) | 176/2200 |
| ||||||||||||
Travel speeds (km/h): | Steering Angle | ±35° |
| |||||||||||||
| I | II |
| Hydraulic System |
| |||||||||||
Forward | 11.5 | 38 |
| Lift Cylinders-Bore× Stroke(mm) | 2-180×721 |
| ||||||||||
Reverse | 16 |
|
| Tilt Cylinder-Bore× Stroke(mm) | 1-200×563 |
| ||||||||||
Engine | WEICHAIWD10G240E24 | Model of Working Pump | Gear Pump |
| ||||||||||||
Rated Power(k w/rpm) | 154/1900 | Flow Rate(L/min/rpm) | 220/2200 |
| ||||||||||||
Rated Torque (Nm/rpm) Starting Voltage (V) | 920/1400-1600 24 | System Pressure(MPa) | 16 |
| ||||||||||||
Pilot Control System Pressure (MPa) | 2.5 |
| ||||||||||||||
Drive Train | Hydraulic Cycle Time, Rated Load in Bucket(in Second): |
| ||||||||||||||
Torque Converter | Single-stage, Duo-turbine, 4-elements | Raise(Loaded) | Dump | Lower(Empty) | Total |
| ||||||||||
Torque Ratio | 4 | 6 | 1 | 4 | 11 |
| ||||||||||
Transmission | Planetary Power shift Transmission | Electrical System |
| |||||||||||||
Gear | 2F/1R | System Voltage(V) | 24 |
| ||||||||||||
Pressure of Transmission(M Pa) | 1.2-1.5 | Battery (2 in series)(Ah) | 120 |
| ||||||||||||
Main Reducer | Spiral Bevel, 1-stage Reduction | Lamp Voltage(V) | 24 |
| ||||||||||||
Final Reducer | Planetary Reduction | Service Refill Capacity |
| |||||||||||||
Tire | 23.5-25 L-3 16PR | Fuel Tank(L) | 285 |
| ||||||||||||
Brake System | Hydraulic Tank(L) | 285 |
| |||||||||||||
Service Brake | Duo Circuit Caliper, Dry Brake | Crankshaft(L) | 20 |
| ||||||||||||
Setting Pressure (MPa) | 0.78 | Transmission(L) | 45 |
| ||||||||||||
Parking Brake | Air Actuated Caliper Brake | Front Axle(L) /Rear Axle(L) | 23/23 |
| ||||||||||||
Emergency Brake | Air Actuated Caliper Brake | |||||||||||||||
Air Conditioning System(Option choose) |
| |||||||||||||||
Heating Capacity(W) | 5300(±10%) |
| ||||||||||||||
Cooling Capacity(W) | 4500(±10%) |
| ||||||||||||||
