製品情報
| 条件: 新しい | 自動等級: 自動 | 力(W): 0.65 |
| 原産地: 中国(本土) | 銘柄: hongxin | モデル番号: hx |
| 次元(L*W*H): 12001500x1600 | 重量: 120kg | 証明: iso |
| 保証: 2年 | または半オート: 自動 |
包装
| 包装: 木の場合 |
仕様
ミニチュアオートメーションの壁のレンダリング機械タイプ800 (輸出志向型)
の販売の工場価格の機械008615238020768を塗るミニチュア自動壁のレンダリング機械乳鉢
利点:
1、 The volume is small、 the weight is light 、 easy to move (、の automatic adjustment of the plaster thickness 、 automatically adjust the plaster joints automatic positioning automatic walking)の 、 easy to operate .
2、The unique design of the dual- rail automatic lift の automatic positioning 、 the main rail design height of 1.96m の host design : wide 78cm x long 80cm . Breakthrough of the biggest challenges of the whitewashed wall machine manufacturers of domestic and market can not solve so far for different floors of a high degree of automatic movements 、 and an effective solution across the room the construction of fills .
3、The machine is designed to squeeze plaster 、 plaster thickness up to 0.2 - 3cm not fall off の further strengthened the bond strength of the mortar and the wall 、 dense degree more than the manual more than five times 、 an effective solution to the artificial plaster in mortar off and hollowing phenomenon .
4、Positioning mode の our company developed a complete positioning system 、 combined with laser positioning ; the positioning is simple 、 fast 、 high precision . Really reached the whitewashed wall of the precedent of automation at home and abroad 、 to effectively guarantee the accuracy of wall roughness and verticality.
5、The professional design of automatic retractable motor adjustment control verticality and the second rail positioning to achieve the plaster 、 the whereab0uts of the mobile location at the same time 、 significant savings in time and solve this problem up outside the host .
6、The unique design of the plaster thickness and the second plaster joints automatic retractable motor adjustment 、 the adjustment range between 2mm - 50mm の free to run 、 to achieve a degree of automation .
7、Yin and yangの the angle forming device is specifically designed based on years of experience in construction company's technical staff .
8、This machine equipped with operating platformの very lightweight、 weighing only 20Kg.The base is provided with a universal wheel、 can be very handy operation.
The main technical performance indicators。
Single-phase motor | 0.65kw | Startup mode | Control button ( distribution box) |
Motor speed | 1440n/min | 減力剤 | Reduction ratio30 : 1 |
Plastering speed | 3.5m/39s | Plaster width | 0.3m- 0.8m |
Plastering height | 0.5- 3.5m | Plaster efficiency | 2.56 m2/39s |
Plastering time | 39s | A plastered area | 2.5m2/39s |
Secondary calendar time | 39s | Secondary pressure light area | 2.5m2/39s |
Flatness error | ≤3mm | Vertical error | ≤ 3mm |
平坦、 plaster thickness 、 | 24v 30w | Walking speed | 10m/ 分 |
Vertical adjustment motor | 24v 30w | Alignment guide motor | 550W |
Walking mot | 550w | 減力剤 | 30 : 1 |
Lifting motor | 0.65kw | 減力剤 | 30 : 1 |
Console shape size | 30cm*50cm*80cm | Console weight | 20kg |
The plaster drive motor | 650w | 減力剤 | 30 : 1 |
The main rail height | 176cm | Positioning rail height | 176cm |
効率: 80m2 / hour
Host Dimensions: 78cm × 80cm × 40cm
Positioning time : 5 seconds
Plaster method: squeeze plaster
Motion way: Walks automatically
Lifting speed : 3.5m/39 seconds .
Machine weight : 80Kg
A plastering width: 80cm
The main rail height: 196cm
30cm X 50cm X 80cm Console Dimensions : 30cm X 50cm X 80cm
Operating weight: 20kg
-----------------------------------------------------------------
PACKING LIST:
Main machine: 95x75x45cm 100kg
Rail : 19070x30cm 90kg
Control cabinet: 8050x40cm 20kg
Total volume: 1.02 cbm
------------------------------------------------------------------
Accessories list (for free):
1.Positioning rule 2.positioning aluminium alloy bar
