製品情報
条件: 新しい | ミキサーのタイプ: ホモジェナイザー | 製品タイプ: 化粧品 |
適用: 液体、 クリーム | 付加的な機能: 製粉 | 原産地: 中国(本土) |
銘柄: guanyu | モデル番号: gye09 | 最高。 積載量: 5000リットル |
電圧: 380v | 証明: ce、 iso9001 | 保証: 12ヶ月 |
提供される売り上げ後のサービス: 利用できるエンジニア機械類を海外に整備するため | 材料: sus304やsus316 |
包装
包装: 合板ケース。 |
仕様
1.真空乳化ミキサー2.油圧式リフト、 plc制御3.sus316l、 sus3044.5l-5000l
Hot sell vAcuum emulsifying mixer
導入:
特徴: stable、 compact、 good quality、 low price
適している: cream、 paste、 ointment、 lotion、 gel、 conditioner、 milk、 sauce、 etc
モデル: Gzgy- a001
容量: 5~5000l
Contact part: suS304/316l (three jackets、 contact ミリアンペアTerial parts adopt suS316l、 the other two layers adopt sus304)
Homogenizer speed: 0~3500rpm
Scraper speed: 0~80rpm
リフティング: hydraulic lifting system
加熱: by steam/電気的に
操作: automatically ( plc)/手動で
クラス: gmp ( オプション)
認証: ce ( オプション)
.
Technical parameter:
モデル | Main pot | Water pot | Oil pot | Main pot power | 油圧 システム | Vacuum pump 電力( kw) | ||||
容量( l) | Wall scraping | ホモジナイザー | ||||||||
Pme-5l | 5l |
|
| 0.18 | 1.1 | 0.75 | 0.55 | |||
Pme-10l | 10l | 8 | 5 | 0.18 | 1.1 | 0.75 | 0.75 | |||
Pme-20l | 20l | 18 | 10 | 0.37 | 1.5 | 0.75 | 0.75 | |||
Pme-50l | 50リットル | 40 | 25 | 0.75 | 4から7.5 | 1.5 | 1.5 | |||
Pme-100l | 100l | 80 | 50 | 1.5 | 4から7.5 | 1.5 | 1.5 | |||
Pme-200l | 200l | 170 | 100 | 2.2 | 7.5-11 | 1.5 | 2.2 | |||
Pme-300l | 300l | 250 | 150 | 2.2 | 7.5-11 | 1.5 | 2.2 | |||
Pme-500l | 500リットル | 420 | 250 | 4 | 11 | 1.5 | 2.2 | |||
Pme-1000l | 千リットル | 820 | 500 | 5.5 | 5 | 2.2 | 3 |
After sales service:
The above machine which we supply it to you、 we can give you one years after sales warranty、 we can also send our engineer to you factory to install this equipment and train your staff、 but the buyer should pay the round air ticket cost and arrange the hotel accommodation as well as the means for seller・rsquo; s engineer。 we will send some free set of spare parts for you change it。
Payment terms:
30% deposit by t/t before production、 70% balance should be paid by t/t before shipment。 We usually take fob、 but we can also accept exw、 cif、 cnf。
パッケージ:
Standard wooden case packing
