製品情報
タイプ: フレキソ印刷のプリンタ | 条件: 新しい | 版のタイプ: スクリーンプリンター |
原産地: 中国(本土) | 銘柄: sunidea | モデル番号: Yt-2600 |
使用法: ペーパープリンター, ラベルプリンター, カードプリンター | 自動等級: 自動 | 色及びページ: 2色 |
電圧: 220v | 全体のパワー: 12kw | 寸法 (L*W*H): 3600*1820*3750mm |
重量: 1500キロ | 証明: ce | 提供される売り上げ後のサービス: 利用できるエンジニア機械類を海外に整備するため |
状態: 新しい | 消費電力( w): 20キロワット | 保証: 1年間 |
アプリケーション: 紙コップ |
包装
包装: 輸出木製ケース海の出荷のためのスーツ |
仕様
紙コップフレキソ印刷機1)に適したティッシュペーパー、 段ボール、 ステッカー
Technical Parameters:
machine model | YT-2600 | YT-2800 | YT-21000 |
printing color | 2 | 2 | 2 |
printing length | 180-960mm | 180-960mm | 180-960mm |
printing plate lifting system | manual | manual | manual |
mechanical speed | 60m/min | 60m/min | 60m/min |
printing speed | 5-50m/min | 5-50m/min | 5-50m/min |
anilox cylinder | me-tal | me-tal | me-tal |
register precision | ±0.5mm | ±0.5mm | ±0.5mm |
rewinder / unwinder diameter | 450mm | 450mm | 450mm |
master motor | 1.5kw | 1.5KW | 1.5KW |
electrical heater | 9KW | 11KW | 13KW |
blower of heater | 300W | 350W | 400W |
inking motor | 0.37KW | 0.37KW | 0.37KW |
master frequency inverter | 1.5KW | 1.5KW | 1.5KW |
weight | 1500kg | 1800kg | 2100kg |
total power | 12kw | 15kw | 18kw |
Applications:
This machine is suitable for printing such packing materials as polyethylene, polypropylene plastic bag, glass paper and roll paper, etc. And it is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.
Technical Features:
1. Easy operation, flexible starting, and accurate color register.
2. Meter counter can set printing quantity according to the requirements. Stop the machine automatically at the set quantity or when the material is cut off.
3. Lift and lower the printing plate cylinder manually, it will automatically stir the printing ink after lifting.
4. The printing ink is spread by the knurled cylinder with even ink color.
5. Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.
6.360°continuous and adjustable longitudinal register device.
7. imp0rted frequency control of motor speed adjusts different printing speeds.
8. There are inching/stopping buttons on plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.
Production Show:
