製品情報
| 条件: 新しい | タイプ: フル生産ライン | コンピュータ化される: はい |
| 原産地: 中国(本土) | 銘柄: comeq | モデル番号: Eq-5-15 |
| 電圧: 380v、 220v、 415v | 力(W): 45-108kw | 保証: 12ヶ月 |
| 提供される売り上げ後のサービス: 利用できるエンジニア機械類を海外に整備するため | フル生産ライン: 5t-25tpd容量 |
包装
| 包装: sea-worthy packaging. |
仕様
5-20t/day抄紙機この生産ラインはトイレットペーパーを製造するために使用、 ナプキン、 またはフェイシャルティッシュ。
Our ServicesFull plant design, Experienced engineer for installation and commissioning at site.
Product Descri-ptionfull production line to produce toilet paper, tissue paper from virgin pulp or waste paper
Packaging & Shippingsteel fra-me, wooden box and other sea-worthy packaging.
FAQPlease note:
OCC and waste newspaper could not be used for recycling into toilet paper.
.
Company InformationMore than 40 years experience on paper machine and have our own paper factory.
Model | EQT05 | EQT 10 | EQT 12 | EQT14 |
Trimmed Paper Width (mm)
| 2,400 | 2,800 | 3,500 | 4,200 |
Basis Weight (g/m2)
| 13-30 | 13-30 | 13-30 | 13-30 |
Design Speed, Yankee (m/min)
| 250 | 280 | 300 | 300 |
Gross Capacity (ton/day)
| 6-7 | 8-10 | 10-12 | 12-15 |
Yankee Diameter (mm)
| 2,500 | 3,000 | 3,000 | 3,000 |
Raw material
| virgin Pulp, waste paper, | |||
Applications: This production line is used to produce toilet tissue, napkin, or facial tissue.
Features:
1) Pressure net vat, spiral welding stainless steel cylinder molding system
2) Equaling design ab0ut flowing speed and flowing equality
3) Pulp entering system with multiple pipe
4) Dewatering system with high efficiency
5) Compound breathing hot wind system (Canadian technology)
6) Compound pneumatic scraper creasing system (Canadian technology)
7) Designing speed: 280m/min
8) Working speed: 130-230m/min
9) Paper weight: 13-30gsm
10) Capacity: 5-20MT/day
11) With water recycling system
