製品情報
条件: 新しい | タイプ: 円 | 適用: 鉱石 |
原産地: 中国(本土) | 銘柄: xkj | モデル番号: yk |
力(W): 5.5-30 | 証明: :2008 | 保証: 1年間 |
提供される売り上げ後のサービス: 利用できるエンジニア機械類を海外に整備するため | 材料: 鋼 | 色: あなた次第 |
スクリーン層: 1- 4 | 容量( トン/h): 30-810 | インストール: 技術指導 |
販売後のサービス: 全体の使用寿命を | 納期: 迅速かつ時間内に。 |
包装
包装: 標準コンテナと海- 立派なパッケージまたは一括で |
仕様
1.高い振動周波数2.多くの画面仕様。 3.ノイズの多い小さな振動。 4.容易なメンテナンス、 競争力のある価格
は、 画面アプリケーションを振動:
このシリーズの円形振動ふるいは石切場に特別に設計された石のサイズが異なるサービスを提供する。 それは石炭のドレッシングにも使われていまし、 鉱石ドレッシング、 建築材料、 電気、 化学産業等。 を採用し、 それにボックス- 振動エキサイターとブロック- 偏心調整。 それ以下のような機能を所有してい、 高度な構造、 安全使用、 強度と振幅調整、 低ノイズ、 頑丈で耐久性のある。
Vibrating screen working principle:
The vibrating screen consists of screen box、 supporting device、 vibration exciter、 transmission part、 etc。 the barrel- type vibration exciter is installed in the middle part of the machine。 during normal operation、 the vibration of exciter will drive the screen mesh fixed on the screen box vibrate、 and then materials will be screened。 the big and small materials fall from the upper side and lower side of the screen to get them separated。
Vibrating screen features and benefits:
It features long flowing line、 many screening specifications、 strong violent force、 high screening efficiency、 small vibrating noises、 firm and durable construction、 convenient maintenance and safe operation。
サービス:
1.プロジェクトのソリューションのための機器または植物;
2.質問や問題のための迅速なフィードバック;
3.すべての技術サポート;
4.手数料とはトレーニングを運営し;
5.の長い期間の保証期間;
ykシリーズ振動ふるいの主な技術パラメータ | |||||||
モデル | 層 | 寸法 サイズ( mm) | 最大。 feed サイズ( mm) | 容量( トン/h) | を振動 周波数 (r/min) | パワー (キロワット) | ダブルスイング (mm) |
2yk1236 | 2 | 1200*3600 | 300 | 30-160 | 970 | 5.5 | 5月9日 |
2yk1545 | 2 | 1500*3600 | 400 | 34-200 | 970 | 11 | 5月9日 |
3yk1545 | 3 | 1500*4500 | 400 | 44-258 | 970 | 15 | 5月9日 |
3yk1548 | 3 | 1500*4800 | 400 | 47-275 | 970 | 15 | 5月9日 |
4yk1548 | 2 | 1500*4800 | 200 | 47-275 | 730 | 18.5 | 5月9日 |
3yk1848 | 3 | 1800*4800 | 400 | 56-330 | 970 | 22 | 5月9日 |
3yk1860 | 3 | 1800*6000 | 400 | 63-586 | 970 | 22 | 5月9日 |
4yk1860 | 4 | 1800*6000 | 400 | 63-586 | 970 | 30 | 5月9日 |
3yk2160 | 3 | 2100*6000 | 400 | 81-720 | 970 | 30 | 5月9日 |
4yk2160 | 4 | 2100*6000 | 400 | は100から800 | 970 | 30 | 5月9日 |
2yk2460 | 2 | 2400*6000 | 400 | 150-810 | 730 | 30 | 5月9日 |
