製品情報
| 原産地: 中国(本土) | 銘柄: longxin | モデル番号: Lx-s球状黒鉛鋳造 |
| 製品: の砂鋳造品 | サービス: 鋳造、 マシニング、 治療、 仕上げ | 鋳造プロセス: 砂型鋳造および遠心鋳造 |
| 溶融: 電気炉 | パターン材: 木製、 アルミニウム製の | 治療: 焼戻し、 正規化、 焼入れ、 ブラスト、 溶接および等 |
| 仕上げ加工: cncボーリング、 cncフライス盤、 旋盤、 掘削、 フライス、 退屈など | プロセス標準: iso、 en、 astm、 din、 jisおよび等 | 工場認定資格: iso14001、 iso9001 |
| 製品認定資格: abs、 bv、 gl、 dnv |
包装
| 包装: 私たちが提供する耐航性のあるパッケージ球状黒鉛鋳造のための木製ケース; が付いている木製パレットフィルムまたはストリップ包まれた |
仕様
球状黒鉛鋳造鉄と鋼鋳物砂型鋳造部品、 遠心鋳造、 マシンabs適合率、 bv、 gl、 dnv
ISO9001 Jiangsu Foundry Spheroidal Graphite Casting
1.Product Descri-ption:
| Product & Service we provide | OEM casting, machining for mechnical me-tal parts |
| Products applied | Marine spare parts, truck parts, railway parts, engineering plant spare parts |
| Casting process | Furan no-bake sand casting & centrifugal casting |
| Process materials | Grey iron, ductile iron, cast steel |
| Products weight | Min:1KG, Max:5000KG |
| Moulding method | Hand molding and machine molding |
| In course treatment | Tempering, normalizing, quenching, blasting, welding and etc |
| Precision machining | CNC boring, CNC milling, lathe, drilling, milling, boring and etc |
| Finish treatment | Polishing, paint, anodizing and galvanizing |
| Certifications in marine industy | ABS,DNV,GL,DNV |
| Factory certifications | ISO9001:2008 ISO14001 |
| Acceptable material standards | GB, JIS, AISI, SAE, ASTM/ASME, EN, DIN, GOST and etc |
| Package & delivery | Wooden pallet or wooden cases; By sea, by land, by air in FCL, or LCL |
2.The iron grades we produce:
| GRAY CAST IRON | |||
Meehante me-tal spec. | GE 200 | GD 250 | GB 300 |
| Brinnel hardness range | 170-210 | 180-220 | 190-230 |
| Min tensile strength | 25,000 psi | 35,00 psi | 45,000 psi |
| 20 Kgf/mm2 | 25 Kgf/mm2 | 30 Kgf/mm2 | |
| American-ASTM 48-83 | GRAY 25 | GRAY 35 | GRAY 45 |
| Germany-DIN1691 | GG 20 | GG 25 | GG 30 |
| Japan-JIS G550 | FC 200 | FC 250 | FC 300 |
| DUCTILE CAST IRON (Nodular Graphite) | ||||
| Meehante me-tal spec. | SFP 400 | SFP 450 | SFP 600 | SFP 700 |
| Brinnel hardness range | 170 Max | 156-217 | 195-217 | 241-302 |
| Elongation % | 18% | 12% | 6% | 3% |
| Min tensile strength | 60,000 psi | 65,000 psi | 80,000 psi | 100,000psi |
| 40 Kgf/mm2 | 45 Kgf/mm2 | 60 Kgf/mm2 | 70Kgf/mm2 | |
| Min yield strength | 32Kgf/mm2 | 33Kgf/mm2 | 39kgf/mm2 | 46Kgf/mm2 |
| 40,000psi | 45,000psi | 55,000psi | 70,000psi | |
| American-ASTM 536-84 | 60-40-18 | 65-45-12 | 80-55-06 | 100-70-03 |
| Germany-DIN1693 | GGG 40 | GGG 45 | GGG 60 | GGG 70 |
| Japan-JIS G 5502 | FCD 400 | FCD 450 | FCD 600 | FCD 70 |
| Carbon Steel | ||||||
| China GB | German | Japan JIS | UK BS | US | ||
| DIN | W-Nr | ASTM | UNS | |||
| ZG200-400 | GS-38 | 1.0416 | SC410 (SC42) | 415-205(60-30) | J03000 | |
| ZG230-450 | GS-45 | 1.0446 | SC450(SC46) | A1 | 450-240(65-35) | J03101 |
| ZG270-500 | GS-52 | 1.0552 | SC480(SC49) | A2 | 485-275(70-40) | J02501 |
| ZG310-570 | GS-60 | 1.0558 | SCC5 | (80-40) | J05002 | |
3. Longxin Poduction Process for Spheroidal Graphite Casting :
Sand casting/centrifugal casting/Forging– Normalizing & tempering – Rough machining-Precision machining- Quenching & Tempering – Finish Machining-Finish treatment-Package and deliver
Process
Firstly, according to customer drawing, our engineer design casting drawing.
1) Material & Mold
==Mold/pattern preparation: carbon steel or other cast steel
Make the mold shape: high precision machining
2) Melting & Pouring: intermediate frequency electric furnace,5 sets, 5000Tons melting capacity.
==Make pilot bar- test chemical composite- if ok, continue the melting
==Pouring and melting temperature test
3) Mould assembling & Open boxes
==Clean the cast and remove the casting head
4) Grind &Polishing
==Clean, sand-blasting
5) Testing Items
==Check the size to the original drawing
==Mechanical test and ultrasonic flaw detection, me-tallographic detection (if customer require)
== Final check according to the drawings
6) Put Casting Goods in storage
==Surface treatment options: polishing, sand blasting, heat treatment, paint, power coating, anodizing, electroplating, mirror polishing
==Precision machining options: CNC, milling, drilling, numerical lathe, peel, polishing and etc
7) Packing & Delivery
==Standard export package (Wooden Case/Bulk/OEM As Request)
==Accept FOB, FAS, CNF, CIF door to door etc or customer designated shipping agent.
the Spheroidal Graphite Casting workshop show:
6.Why choose Longxin Foundry to be your long-term partner?
- 10 years experiences in marine casting, stable and respectable supplier for European companies for 7 years
- Advanced furan no-bake sand molding process, centrifugal casting process can meet almost all of the mechnical parts
- Quality assured: ABS,BV,DNV,GL classications' approved, very impressive in marine industry
- Professional exporting department, one stop from your drawing, to your requested well machined parts
- Easy transportation, close to Shanghai seaport, and 1 hours car ride to Suzhou, Changzhou and Wuxi
- Efficient production and management, quick response and high responsibility to customers' feedbacks and claims
- 3D CAD drawings acceptable
