製品情報
| 標準的なか標準外: 標準 | タイプ: 平らなベルト | 材料: 綿のファブリックとゴム材料 |
| 原産地: 中国(本土) | 銘柄: kaidiまたはoem | モデル番号: 100mmx4px100m、 80mmx6px100m |
| 色:: 黒、 黄色、 赤、 オレンジ、 白、 緑、 青 | 幅:: 50mm-1400mm | プライ:: 2ply-8ply |
| 長さ:: 100m-200m/roll | 厚さ: 1.1mm/ply | 生産標準: Gb/t7984-2001、 din22102、 bs490、 as1332、 rma、 jisk6322、 sabs1173 |
包装
| 包装: 不織布バッグとパッキング。 読み込むことができ1x20ftto350bags300袋について |
仕様
フラット伝動ベルト: 1,高品質の綿のキャンバス。 2,高強度と優れた柔軟性。 3,使用中の小さな伸び。
1.Features:
1).Flat transmission belt is a common flat rubber belt, also called transmission belt,
usually uses high quality cotton canvas as its skeleton layers. After the surface of
the canvas is scrubbed and coated with appropriate rubber, several layers of
rubber canvas adherer together to form the flat rubber belt. On the longitudinal
seam of the belt, enclosing rubber is used to make the seam firmer, and
better-adhered together better.
2).The flat rubber belt has the characteristics of high strength, good flexibility, and
small elongation. It is mainly used in factories, mines, docks, me-tallurgical industry,
and also widely used in ordinary mechanical power transmission, great power
processing of grains like rice and wheat, irrigation equipment, wood cutting and
other power transmitting equipment for industry and agriculture. Therefore it
plays a more and more imp0rtant role in various types of power transmitting
equipment.
2.the flat transmissiom belt can be divided into two kind:
1) fold edge type: the outermost layer canvas or multilayer canvas of round edged transmission belt be wraped up, the side of the belts’ curved.
2) cut edge type: cut edged transmission belt is made by adhering several layers of full width canvas together. The sides of the belts are flat surfaces by cutting. The edges of belt are coated with rubber paste.
3.oversea market:
we mainly export asia countries such as vietnam, thailand, india,pakistan and bangladesh. africa countries such as Mali, Nigeria,Egypt,and cameroon. south america such as brazil and chile. we also have customers from russia and kazakhstan.our flat belt are very popular in these countries for its good and stable quality with competitive price.
4.Physical property:
1.Overall thickness tensile strength of flat transmission belt
Tensile strength specification | Overall thickness tensile strength | Reference number of canvas layers | |
Vertical minimum | Horizontal minimum | ||
190 | 190 | 75 | 3 |
240 | 240 | 95 | 4 |
290 | 290 | 115 | 5 |
340 | 340 | 130 | 6 |
385 | 385 | 225 | 7 |
425 | 425 | 250 | 8 |
450 | 450 | / | 9 |
500 | 500 | / | 10 |
2.Elongation at break,in vertical tensile test,the elongation at break should not exceed 20%.
3.Adhesion strength,adhesion between flat belt layers is no less than 3.0KN/M.
Products specification
With(mm) | Plies | Width tolerance(mm) |
20.25.30.40.45.50.55.60 | 3-4 | ±2 |
65.70.75.80.90.100.125 | 3-6 | ±3 |
140.160.180.200.224.225 | 4-6 | ±4 |
288.300.315.350.400.450.550.600 | 4-10 | ±5 |
belt show:
TAIZHOU KAIDI RUBBER PLASTIC CO.,LTD
WELCOME FOR YOUR PATRONAGE!!!
