製品情報
| 原産地: 中国(本土) | 銘柄: fullda | モデル番号: dcモータ |
| 使用法: 家庭電化製品 | 証明: セリウム | タイプ: ギヤモーター |
| 代わり: ブラシ | 特徴を保護しなさい: 全く封じられた | 出力電力: 250w-300w |
| 電圧（V）: 110v/220v | 効率: IE 4 | 名: dcモータ |
| 定格電力: 240( w) | パワーリフティング: 600( kg/f) | 出力トルク: 408( n- m) |
| 出力速度: (r- 分) | 最大揚程: 6( m) | チェーン番号: 10a |
| 該当する電圧: 220v/50hz |
包装
| 包装: Dcモーター---- 2カートン泡の中で |
仕様
ローラードア用dcモータ電源: 250ワット- 300w昇降: 300kg/500kg/600kg/1000-- 2000キロ抗- 雷/with安全
Product Descri-ption
1.Product features
DC motor
1) Elegant appearance, advanced structure, powerful motor
2) imp0rted electrical components, secure and stable
3) Low noise, small vibration, less power consumption
4) Light, small, easy installation, long service life, and reliable performance;
5) With remote control function, support long distance control
6) With reserve device, could maintain universal operation when power off
7) The battery (4Ah/12V) is the universal product in the market
8) Use safe voltage, more secure/safe
2.Function introduction
DC motor
DC 24V 600KG roller door motor/operator/opener is the new product of second generation developed by our company, with more remarkable capability, simpler installation, and more reliable operation.
roller door motor
1) Remote function: upward/stop,downward/stop
2) Hand control function:upward/stop,downward/stop
3) Equipped with reserve battery: in normal power supply case, the motor worked by 24V power supply, and once if the power off, it automatically supplied by the reserve battery, and could keep the motor running up and down for ab0ut 20 times.
4) Low voltage alarm: once the reserve voltage is below to 18V±05.V, it sounds of bee bell warning.
5) DC 24V 600KG roller door motor/operator/opener is belong to the short-time working, one day running time accumulated shall not be more than 30 minutes.
3.Parameters
DC motor
Items | Technical Parameters |
Applicable voltage | 220V/50Hz |
Rated power(W) | 240 |
Lifting power(kg/f) Output torque (N-m) Output speed (r-min) | 600 408 5 |
The maximum lifting height (m) | 6 |
The maximum rolling door diameter (m) | 0.4 |
|
|
Chain number | 10A |
The main engine weight | 8.4kg |
