製品情報
| 原産地: 中国(本土) | 銘柄: HL | タイプ: 網のフィルター・バッグ |
| 使用法: 液体フィルター | 袋の材料: PP |
包装
| 包装: carton |
仕様
1.Liquid Filter Bag Material:PP/PO/PE/NMO/PTFE 2.Liquid Fitler Bag Size:1~4Customized 3.Usage:Liquid Filter
Liquid Filter Bag
HL FILTER, the largest manufacturer of liquid filter bags in China. ISO9001, FDA, EC Food-Contact certificated!!
Material: PP/PO/PE/NMO/PTFE
Usage: Liquid Filter
Cloth: Needlefelt or Mesh
Size: Standard #1~#4 or Customized
Ring Material: Plastic (PP/PO/PE) or SS (Stainless Steel) or Carbon Steel or Zinc Steel
Seam Method: Welded or Sewn
Micron Rate: 0.5,1,5,10,25,75,80,100,125,150,200,250,300 thru 800
Surface treatment: Singed finished and glazed finish
Application:
- Automotive
- Food and Beverage
- Chemical Processing
- Paints, Inks, Resins and Coatings
- Electronics
- Oil and Gas
- Municipal Water
- Industrial Water
- Pulp and Paper
- Pharmaceutical
- Lubricants, me-talworking Fluids
- Solvents
Bag size | Filter Area(㎡) | Volume(Litre) | Max. Flow(m³/h) | Diameter | Length |
P1S | 0.25 | 8 | 20 | 7”(180mm) | 17”(450mm) |
P2S | 0.5 | 17 | 40 | 7”(180mm) | 32”(810mm) |
P3S | 0.09 | 1.3 | 6 | 4”(105mm) | 9”(230mm) |
P4S | 0.16 | 2.5 | 12 | 4”(105mm) | 15”(380mm) |
Micron | 1000 | 840 | 710 | 590 | 500 | 420 | 350 | 297 | 250 | 210 | 177 | 149 |
Mesh | 18 | 20 | 25 | 30 | 35 | 40 | 45 | 50 | 60 | 70 | 80 | 100 |
105 | 88 | 74 | 62 | 53 | 44 | 37 | 30 | 20 | 15 | 10 | 5 | |
140 | 170 | 200 | 230 | 270 | 325 | 400 | 500 | 625 | 1000 | 1250 | 2500 |
Our Factory
