製品情報
条件: 新しい | 原産地: 中国(本土) | 銘柄: chuangda |
モデル番号: Cd-150i | 電圧: 380v | 力(W): 7キロワット |
次元(L*W*H): 4000*2540*1600 | 重量: 2000キロ | 証明: ce |
保証: 1年間 | 提供される売り上げ後のサービス: 利用できるエンジニア機械類を海外に整備するため | 原料: スパンレース不- 不織布 |
証明書: ce | 製品タイプ: 缶型ウェットティッシュ | サービスタイプ: oem |
折りたたみタイプ: 折り畳むことができ" c" タイプ | 制御システム: plc | 機械材料: ステンレス鋼 |
速度制御: サーボモータ制御 |
包装
包装: 木の場合。 |
仕様
1)フルオート2)高速3)容易な操作。 4)スペースを節約する
Main techinical parameter: | |
Power supply: | 380v 50hz |
パワー: | 9キロワット |
Production speed: | 90m/min |
Folding way: | ・ldquo; c& rdquo; folded or without folding |
Max size of wet tissue roll: | ø 1200 * w( length is unlimited) |
穴- punching length: | 100〜300ミリメートル |
Control system: | Plc control system、 color touching screen |
Suitable raw material: | 空気- laid paper、 spunlace non- woven fabric、 非- woven fabric |
Gsm of raw material: | 20-75g/m2 |
Max size of raw material: | 1200 * 1500mm( d*w) |
Water tank size: | 800*800*2100mm( l*w*h) |
Machine size: | 4000*2540*1600mm( l*w*h) |
Weight of machine: | 2000キロ |
Automatic pneumatic feeding material system、 electrical eye tracks automatically | |
Making option: 1. three meters of conveying shelf 2. full servo motor。 |
