製品情報
| ～に使う: 乗客 | ドライブの種類: モーターを備えられる | 変位: 151 - 200cc |
| ボディタイプ: 開いた | 証明: EPA | 銘柄: -- |
| 原産地: 中国(本土) | モデル番号: GT200SL-1 | サイズ: -- |
包装
| 包装: Carton and Iron fra-me |
仕様
Wheel Base (mm):1750 Net Weight (kg):188 Max. Load Weight (kg):150
Motorcycle(GT200SL-1)
Engine Type: | 189cc, 161QML,single,oil cooled ,4 stroke. | ||
Max. Power (kw/r/min): | 7.3/7000 | Max. Torque (N.m/r/min): | 10.2/5000 |
Bore stroke (mm) | 61 x 57.8 | Compression ratio | 9.2:1 |
Starting System: | Electric/kick | Ignition Mode: | CDI |
Transmission: | Belt | Clutch type | Automatic,Centrifugal |
Max Speed | 70km/h | Engine oil capacity | 0.9 |
Oli grade | SAE10W-40 | Carburetor | PD24J |
Fuel Tank Capacity (L): | 12 |
|
|
CHASSIS | |||
Front/Rear Brake: | Front/Rear disc brake | Battery: | 12V/9Ah |
Head light | 12v/35w | Turn signal | 12v/10w |
Tail light | LED | License plate lamp | 12v/5w |
Front Tire: | 130/60-13 | Rear Tire: | 235/30-12 |
Spark Plug | A7TC | Spark Plug clearance | 0.6-0.7(mm) |
DIMENSIONS | |||
L X W X H (mm): | 2, , , 400×1090×1, , , , , , 100 | Net Weight (kg): | 188 |
Wheel Base (mm): | 1750 | Max. Load Weight (kg): | 150 |
OTHERS | |||
Container Loading: | 20"GP:10 pcs 40"HQ:20 pcs | ||
