製品情報

原産地: 中国(本土)	銘柄: labeyond	モデル番号: 1901-j/a/b/uv、 1903年、 1905年、 1906年
色: 顧客ごとの要求として	アプリケーション: ケーブルの化合物、 酸素- 抵抗層、 注入材料	認証: Jb/10437t
ホット変形パーセント: 15/16/18	材料: 熱可塑性ポリオレフィン/tpo	特徴: 難燃剤、 lzhffr、 断熱材、 アンチクラック、 uv- 証拠

仕様

1.注入材料/tpo2.hffr3.絶縁4.35kvまで5.私達は12年間の取引経験



 Product Descri-ption

  low-smoke halogen free flame retardant injection material/tpo



This series is polyolefin compound for cable and jacket of cables which is flame retardant.

They are applied to insulation and jackets of power cables/sheathing up to 35kv.

The specification can meet the requirements of JB/T10437.



Thermoplastic LSZH FR polyolefin cable compound
Name	Type	Density g/cm3	Elongation at Break %	Tensile Strength MPa	Hot Deformation (90°C×4h)%	OI%
90°C jacketing compound	1901	1.46	220	11.8	15	35
90°C cable compound	1901-J	1.46	210	11.7	16	32
90°C anti-cracking jacketing compound	1901A	1.41	280	12.5	15	32
90°C anti-cracking jacketing compound	1901B	1.45	220	12.0	15	34
90°C UV-proof jacketing compound	1901-UV	1.45	220	12.0	15	34
90°C oxygen- resisting layer	1903	1.59	180	10.5	--	45
90°C njection material	1905	1.23	260	10.5	--	27
90°C anti-cracking soft jacketing compound	1906	1.43	230	11.2	18	32



 Note: 1901 pass thermal shock(150°C×1h)

          1901A, 1908 pass thermal shock(150°C×1h),load 10kg

          1901b,1907 pass thermal shock(150°C×1h),load 5kg





We also supply: peroxide XLPE compound ,silane-XLPE compound, PVC compound , which applied to insulation and jackets of power cables up to 35kv .

 Packaging & Shipping



We could support packaging agreed on by both manufacturer and client !
