製品情報
| 原産地: 中国(本土) | 銘柄: LC | モデル番号: LC503 |
| 証明書: ISOの9001:2008 | 色: 透明 | テストレポート: ROHS/REACH |
| 材料: 合成ポリマー | タイプ: 総合的な樹脂およびプラスチック | MFR: 6-8 g/10min |
| 他の名前: F-26 | 利点: 高温抵抗 |
包装
| 包装: 25kgs/bag/carton |
PVDF (Polyvinylidene Fluoride) plastics is a novel fluorocarbon thermal plastic resin with some advantages of fluorine containing resins and common resins. It has excellent resistance to chemical corrosionの high temperature and oxidation、 it also has high mechanical strengh、 toughness、 outstanding weather resistance、 UV resistance、 radiation resistance、 and outstanding dielectricity piezoelectricity and thermal electricity etc.
特徴: 、 corrosion prevention low friction coefficient、 Strong obdurability aging resistance、 climate resistance、 and radiation resistance.
適用: Used in acid and alkali resistance、 corrosion prevention、 friction coefficient products such as injection、 cover cable、 electric wire etc.
PVDF Technical Parameter ( Item No. : LC503 )
Physical Performance | Specific Gravity (g/cm3) | 1.75-1.79 |
Melting Point (°C) | 160-170 | |
Mechanical Performance | Tensile Strength (MPa) | 18-22 |
Breaking Extension (%) | 50-250 | |
Compression Intensity (MPa) | 50-100 | |
Shore Hardness | 115 | |
Coefficient of Kinetic Friction | 0.3 | |
Melting Index | 6-8 | |
Thermal Performance | Maximal Temperature of Continuous Work (°C) | 125 |
Thermal Distortion Temperature (°C) (1.82 MPa) | 100 | |
Coefficient of Linear Expansion x105(K- 1) | 7-14 | |
Electrical Performance | Volume Resistance (Ω·cm) | 1015 |
Insulation Breakdown Voltage (3.2mm) | 12 | |
Relative Dielectric Constant (1KHz) | 7 | |
Dielectric Loss Angle Tangent Value (tanδ) (X106Hz) | 0.1 |
